Magnetek Flex M - Page 43

Flex M Engineered Receiver Instruction Manual
May 2019
Page 43 of 50
Channel
Frequency
SW1
SW2
SW3
SW4
SW5
AK01
439.8
UP
DOWN
DOWN
DOWN
DOWN
AK02
439.6
DOWN
UP
DOWN
DOWN
DOWN
AK03
439.4
UP
UP
DOWN
DOWN
DOWN
AK04
439.2
DOWN
DOWN
UP
DOWN
DOWN
AK05
439.0
UP
DOWN
UP
DOWN
DOWN
AK06
438.8
DOWN
UP
UP
DOWN
DOWN
AK07
438.6
UP
UP
UP
DOWN
DOWN
AK08
438.4
DOWN
DOWN
DOWN
UP
DOWN
AK09
438.2
UP
DOWN
DOWN
UP
DOWN
AK10
438.0
DOWN
UP
DOWN
UP
DOWN
AK11
437.8
UP
UP
DOWN
UP
DOWN
AK12
437.6
DOWN
DOWN
UP
UP
DOWN
AK13
437.4
UP
DOWN
UP
UP
DOWN
AK14
437.2
DOWN
UP
UP
UP
DOWN
AK15
437.0
UP
UP
UP
UP
DOWN
AK16
436.8
DOWN
DOWN
DOWN
DOWN
UP
AK17
436.6
UP
DOWN
DOWN
DOWN
UP
AK18
436.4
DOWN
UP
DOWN
DOWN
UP
AK19
436.2
UP
UP
DOWN
DOWN
UP
AK20
436.0
DOWN
DOWN
UP
DOWN
UP
AKA00
433.125
UP
DOWN
UP
DOWN
UP
AKA01
433.325
DOWN
UP
UP
DOWN
UP
AKA02
433.525
UP
UP
UP
DOWN
UP
AKA03
433.725
DOWN
DOWN
DOWN
UP
UP
AKA04
433.925
UP
DOWN
DOWN
UP
UP
AKA05
434.125
DOWN
UP
DOWN
UP
UP
AKA06
434.325
UP
UP
DOWN
UP
UP
AKA07
434.525
DOWN
DOWN
UP
UP
UP
AKA08
434.725
UP
DOWN
UP
UP
UP
Table 5. CHANNEL DIP SWITCH SETTINGS FOR 433MHZ (TELEMOTIVE CHANNEL SET) RF/CPU MODULE
