• CAN 1 Source Addr - This is the address that the MHR will use as the source address
when transmitting messages on the CAN 1 bus network.
• 0 through 255
• CAN 1 Identifier Bit - This option allows the operator to select between an 11 bit or 29 bits
identifier for the CAN 1 network
• 11 bits
• 29 bits
• CAN 1 Term Resistor - This option allows the user to enable/disable the internal
terminating resistor.
The options for the terminating resister are:
• Internal
• External
Selecting Internal will enable the terminating resistor. Selecting External will disable the
internal terminating resistor.
The options menu continues with the CAN 2 settings and they have the same options as the CAN
1 settings detailed above.
The list of the CAN 2 network options are:
• CAN 2 Protocol
• CAN 2 Baud Rate
• CAN 2 Source Addr
• CAN 2 Identifier
• CAN 2 Term Resistor
Press the
button to return to the CAN setting option menu.
3.6 PROJECT SPECIFIC OPTIONS
This option menu item features custom configuration options that were put onto the MHR by
customer request.
Reference the project documentation that was shipped with the MHR for details or contact the
factory.
3.7 UNIT STATUS
This section displays the unit status information (see Figure 16 for details).
There are no user selectable options in this menu item.
To exit the unit status screen, press the
button to return to the main setup menu screen.
