46-605 Flanged External Cage Float Actuated Liquid Level Switches
19
6.1.4 Models D30, J30 and L30
Housing cover Refer to Section 6.1.2
Housing base Refer to Section 6.1.2
Switch mechanism Refer to Section 6.1.2
Enclosing tube kit ➀ ➁ 089-5915-001 089-5933-011
includes items 4 and 5
Enclosing tube gasket 012-1204-001 012-1301-002
Head flange kit 089-4204-001 089-4205-001
includes items 5, 6, 7, 8, and 9
Flange gasket 012-1301-023 012-1301-026
Float chamber kit
➂ 089-4604-001 089-4605-001
includes items 7, 8, 9, and 10
Float and stem assembly ➀ 089-3204-001 089-3205-001 089-3206-001
includes items 9, 11, 12, 13, 14, 15, 16, and 17
Complete control ➀ √ 089-6569-002 not available
less float chamber (10), bolts (7), and nuts (8)
D30 J30 L30
6.1.5 Models B60 and C60
Housing cover Refer to Section 6.1.2
Housing base Refer to Section 6.1.2
Switch mechanism Refer to Section 6.1.2
Enclosing tube kit: includes items 4 and 5 ➀ 089-5933-004 089-5933-011
Enclosing tube gasket 012-1204-001 012-1301-002
Head flange kit: includes items 5, 6, 7, 8, and 9 089-4206-001 089-4206-002
Flange gasket 012-1204-015 012-1301-024
Float chamber kit: ➂ includes items 7, 8, 9, and 10 089-4606-001 089-4606-002
Float and stem assembly: includes items 9, 11, 12, 13, 14, 15, 16, and 17 ➀ 089-3208-001 089-3209-001
Complete control less float chamber (10), bolts (7), and nuts (8) ➀ √ 089-6568-004 089-6568-003
B60 C60
NOTE: All replacement assemblies listed are furnished in kit form for standard base models. Consult local representative for ordering assistance
on all special model replacement parts or accessories not included in above listing.
➀ For models with -2 material codes, consult factory for spare parts.
➁ Model D30 unit is specially designed for Dowtherm “A” service only, with Hastelloy C enclosing tube.
➂ Kits are units with 1” NPT or SW side/bottom connections. For other configurations, consult factory.
√ Furnished with one Series C, SPDT Snap Switch and NEMA 4X/7/9 cast aluminum switch housing.
