Magnetrol B60 - Model C29; Models D30, J30 and L30; Models B60 and C60

46-605 Flanged External Cage Float Actuated Liquid Level Switches
21
6.2.3 Model C29 TDM
Housing kit: includes items 1 and 2 Refer to Section 6.2.2
Switch mechanism Refer to Section 6.2.2
Enclosing tube kit: includes items 4 and 5 89-5909-002
Enclosing tube gasket 12-1204-001
Head flange kit: includes items 5, 6, 7, 8, and 9 89-4203-001
Flange gasket 12-1301-025
Upper float and stem kit: includes items 9, 10, 11, 12, 13, 14 and 15 89-3217-001
Lower float and stem kit: includes items 9, 16, 17, 18 and 19 Special order ➀
Float chamber kit: includes items 7, 8, 9, and 20 Special order ➀
6.2.4 Models D30 TDM, J30 TDM and L30 TDM
Housing kit: includes items 1 and 2 Refer to Section 6.2.2
Switch mechanism Refer to Section 6.2.2
Enclosing tube kit 089-5909-002
includes items 4 and 5
Enclosing tube gasket 012-1204-001
Head flange kit 089-4204-001 089-4205-001
includes items 5, 6, 7, 8, and 9
Flange gasket 012-1301-023 012-1301-026
Upper float and stem kit 089-3218-001 089-3219-001 089-3220-001
includes items 9,10,11,12,13,14, and 15
Lower float and stem kit Special order
➀
includes items 9, 16, 17, 18, and 19
Float chamber kit Special order
➀
includes items 7,8 9, and 20
D30 TDM
➁
J30 TDM L30 TDM
6.2.5 Models B60 TDM and C60 TDM
Housing kit: includes items 1 and 2 Refer to Section 6.2.2
Switch mechanism Refer to Section 6.2.2
Enclosing tube kit: includes items 4 and 5 089-5933-004 089-5933-011
Enclosing tube gasket 012-1204-001 012-1204-001
Head flange kit: includes items 5, 6, 7, 8, and 9 089-4206-001 089-4206-002
Flange gasket 012-1204-015 012-1301-024
Upper float and stem kit: includes items 9, 10, 11, 12, 13, 14, and 15 089-3222-001 089-3223-001
Lower float and stem kit: includes items 9, 16, 17, 18, and 19 Special order ➀
Float chamber kit: includes items 7, 8, 9, and 20 Special order ➀
B60 TDM C60 TDM
NOTE: All replacement assemblies listed are furnished in kit form for standard base models. Consult local representative for ordering assistance
on all special model replacement parts or accessories not included in above listing.
➀ Specify model and serial number when ordering special order items.
➁ Model D30 unit is specially designed for Dowtherm “A” service only, with Hastelloy
®
C enclosing tube.
