BE 58-602 Pulsar
®
Model R96 Radar Transmitter
Select the Units of measurement for the level readout:
• Inches • Feet • Millimeters • Centimeters • Meters
Enter tank height (in Level Units selected)
Select the Antenna Model to be used with Model R96 (refer to antenna nameplate):
• RAA-x — TFE rod
• RAB-G — Polypropylene rod
• RAB-L — Polypropylene rod
• RAB-x — Polypropylene rod
• RAC-x — Halar rod
• RA3-x — 3" horn
• RA4-x — 4" horn
• RA6-x — 6" horn
0 For nozzle height ≤ 25 mm (1") (for threaded process connection only) (refer to antenna
nameplate):
1 For nozzle height ≤ 100 mm (4")
2 For nozzle height ≤ 200 mm (8")
3 For nozzle height ≤ 300 mm (12")
Select the type of Antenna Mounting to the vessel (refer to antenna nameplate):
• NPT (National Pipe Thread)
• BSP (British Standard Pipe)
• Flange (ASME or EN)
Enter the Dielectric Range for the material to be measured.
Below 1.7 (Light Hydrocarbons like Propane and Butane) — (stillwell only)
1.7 to 3.0 (Most typical hydrocarbons)
3.0 to 10 (Varying dielectric, for example: mixing tanks)
Above 10 (Water-based media)
Enter the level value (0 %-point) for the 4 mA point. Lower Range Value (LRV).
Refer to Section 1.4.1.1.
Enter the level value (100 %-point) for the 20 mA point. Upper Range Value (URV).
Refer to Section 1.4.1.1.
Enter the desired output state when a Failure Indicator is active.
• High (22 mA)
• Low (3.6 mA)
• Hold (Hold last value is not recommended for standard configuration). Consult factory for
use.
