BE 58-602 Pulsar
®
Model R96 Radar Transmitter
1.0 QuickStart Installation
The QuickStart Installation procedures provide an overview
of the key steps for mounting, wiring, and configuring the
PULSAR Model R96 radar level transmitter. These proce-
dures are intended for experienced installers of electronic
level measurement instruments.
See Complete Installation, Section 2.0, for detailed installa-
tion instructions.
1.1 Getting Started
Before beginning the QuickStart Installation procedures,
have the right equipment, tools, and information available.
No special tools are needed. The following items are
recommended:
• Threaded antenna and process connection . . . . 2" (50 mm)
• Transmitter/antenna connection . . 1 3/4" (44 mm) wrench
• Transmitter adjustment . . . . . . . . . 1 1/8" (28 mm) wrench
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3/32" Hex wrench
• Torque wrench . . . . . . . . . . . . . . . . . . . . . . highly desirable
• Flat-blade screwdriver
• Digital multimeter or volt/ammeter . . . . . . . . . . . Optional
• 24 VDC (23 mA) power supply . . . . . . . . . . . . . . Optional
