19
7.Put
7.Put the label on the R.H. lever guide as
shown in the gure below.
6.
6.Install the knob.
5.
5. Install the R.H. lever guide with four bolts
(M6x16mm,M6x20mm) and a nut (M6).
Tighten the bolts and nut to the following
torque. 4-5Lbf
ft (4.9-6.9Nm).
In the case of gear speci cations, connect
the harness of the IND PTO switch.
KNOB
KNOB
R.H. LEVER GUIDE
R.H. LEVER GUIDE
2.2 Inch (55mm)
2.2 Inch (55mm)
1.Connect the ground cable to the battery.
GROUND CABLE
GROUND CABLE
BATTERY
BATTERY
INSTALLING GRIP
1.
1. Install the grip to the Aux. lever and posi-
tion lever.
Apply a quick-drying glue to grips.
POSITION CONTROL
POSITION CONTROL
LEVER
LEVER
AUX. LEVER
AUX. LEVER
GRIP
GRIP
GRIP
GRIP
CONNECTING GROUND
CABLE
R.H. LEVER GUIDE
R.H. LEVER GUIDE
LABEL
LABEL
