Mahindra 3016 User Guide

1
TABLE OF CONTENTS
ABOUT THIS MANUAL ......................................................... 2
SAFETY ................................................................................ 3
INTRODUCTION .................................................................. 4
RIGHT HAND AND LEFT HAND SIDES OF THE TRACTOR ...... 4
TORQUE SPECIFICATION .................................................. 5
CONTENTS OF AUXILIARY VALVE KIT ............................. 6
PARTS LIST OF AUXILIARY VALVE KIT ............................. 7
BEFORE IT WORKS ............................................................. 8
DISASSEMBLING SEAT BRACKET AND COVER ............. 8
DISASSEMBLING REAR WHEEL R.H. ................................10
DISCONNECTING LEVER AND HYDRAULIC BLOCK .......10
ASSEMBLING AUX. VALVE KIT ..........................................11
INSTALLING AUX. ARM ......................................................12
INSTALLING BLOCK ...........................................................13
INSTALLING AUX. VALVE ASSEMBLY ..............................14
INSTALLING AUX. LEVER ..................................................14
INSTALLING POSITION CONTROL LEVER .......................15
INSTALLING BRACKET .......................................................15
INSTALLING COUPLING ASSEMBLY .................................16
CONNECTING HOSE A ........................................................16
INSTALLING REAR WHEEL R.H. ........................................17
INSTALLING SEAT BRACKET AND COVER ......................18
INSTALLING GRIP ................................................................19
CONNECTING GROUND CABLE .........................................19
OPERATION .........................................................................20

Mahindra 3016 Specifications

General

Engine Power	30 HP
Engine Cylinders	3
Drive Type	4WD
Engine Type	Diesel
Tire Size (Front)	7-16
Transmission	8 Forward / 2 Reverse
Fuel Tank Capacity	32 L
Tire Size (Rear)	12.4-24
