easyTymp® Operating Manual
6
3.2.1.2 Cradle indication lights
Depending on the version (with or without printer) the cradle has up to three indication lights.
shows solid blue when the easyTymp®
is placed inside the cradle and the battery is fully charged.
The LED will flash as long as the battery is charging.
Battery LED shows solid blue when the spare battery in
the cradle is fully charged. The LED will flash as long as
the battery is charging.
Printer LED is red when a printer problem occurs.
3.2.1.3 Installing paper in the thermal printer
Step 1 - Push button to open the printer cover
Step 2 – Pull blue lever upwards
Insert paper roll in the compartment with its loose e
nd
to the front of the printer. Position the loose end into
the printer roll and hoist it by rotating the printer roll
with your finger
