Makita LD080PI User Manual

Makita LD080PI
Measuring Functions
10
EN
Pythagoras (2-point)
1
3x
2
Aim laser at up-
per point.
3
4
Aim laser rectan-
gular at lower
point.
8.294 m
5
i
Notice additional
Pythagoras
measurement in-
formation at the
bottom of the
next page.
Pythagoras (3-point)
1
4x
2
Aim laser at up-
per point.
3
4
Aim laser at rec-
tangular point.
5
6
Aim laser at lower point.
8.294 m
7
i
Notice additional
Pythagoras
measurement in-
formation at the
bottom of the
next page.

Makita LD080PI Specifications

General

Product color	Black, Blue
Memory function	Yes
Electronic compass	-
Display number of lines	3 lines
Distance measuring units	cm, m, mm
Number of memory records	20
International Protection (IP) code	IP54
Accuracy	1.5 mm
Wavelength	635 nm
Laser class	2
Sensor tilt angle	180 °
Maximum measurement distance	80 m
Minimum measurement distance	0.05 m
Battery type	AAA
Battery life (measurements)	5000

Weight and Dimensions

Depth	32 mm
Width	57 mm
Height	117 mm
Weight	140 g
