Makita LD080PI User Manual

Makita LD080PI
7
EN
Measuring Functions
Measuring single distance
1
Aim active laser at target.
2
8.532 m
3
i
Target surfaces: Measuring
errors can occur when meas-
uring to colourless liquids,
glass, styrofoam or semi-per-
meable surfaces or when
aiming at high gloss surfac-
es. Against dark surfaces the
measuring time increases.
Permament / Minimum-Maximum measuring
1
2 sec
8.532 m
Used to measure room diagonals (maximum val-
ues) or horizontal distance (minimum values)
The minimum and maximum dis-
tance measured is displayed
(min, max.). The last value meas-
ured is displayed in the main line.
min. max.
2
Stops permanent / mini-
mum-maximum measuring.
3
Add / Subtract
7.332 m
1
The next meas-
urement is added
to the previous
one.
2
The next meas-
urement is sub-
tracted from the
previous one.
5.515 m
12.847 m
3
i
The result is shown in the
main line and the measured
value above. This process
can be repeated as required.
The same process can be
used for adding or subtracting
areas or volumes.

Makita LD080PI Specifications

General

Product color	Black, Blue
Memory function	Yes
Electronic compass	-
Display number of lines	3 lines
Distance measuring units	cm, m, mm
Number of memory records	20
International Protection (IP) code	IP54
Accuracy	1.5 mm
Wavelength	635 nm
Laser class	2
Sensor tilt angle	180 °
Maximum measurement distance	80 m
Minimum measurement distance	0.05 m
Battery type	AAA
Battery life (measurements)	5000

Weight and Dimensions

Depth	32 mm
Width	57 mm
Height	117 mm
Weight	140 g
