Measuring Functions
12
EN
Stake out
1
2
3
1.000 m
1
6x
0.625 m
2
Adjust
value.
3
Approve value and
start measurement.
4
Move device
slowly along the
stake-out line.
The distance to
the next stake
out point is dis-
played.
0.625 m
0.240 m
0.240 m is missing
up to next 0.625 m
distance.
i
When approaching a stake
out point to less than 0.1 m
the instrument starts to
beep.
The function can be stopped
by pressing the CLEAR/OFF
button.

Makita LD080PI Specifications

General

Product color	Black, Blue
Memory function	Yes
Electronic compass	-
Display number of lines	3 lines
Distance measuring units	cm, m, mm
Number of memory records	20
International Protection (IP) code	IP54
Accuracy	1.5 mm
Wavelength	635 nm
Laser class	2
Sensor tilt angle	180 °
Maximum measurement distance	80 m
Minimum measurement distance	0.05 m
Battery type	AAA
Battery life (measurements)	5000

Weight and Dimensions

Depth	32 mm
Width	57 mm
Height	117 mm
Weight	140 g
