Measuring Functions
11
EN
Pythagoras (partial height)
1
5x
2
Aim laser at up-
per point.
3
4
Aim laser at 2nd
point.
5
6
Aim laser at rec-
tangular point.
2.602 m
7
i
• The result is shown in the main line and the measured distance above.
• A reduced level of accuracy, lower than the level of accuracy of the instrument
itself, must generally be expected when the Pythagoras measuring method is
used. In order to obtain the best results we recommend to use a tripod or to flip
out the corner end piece.
• Pressing the measuring key for 2 sec in the function activates automatically
Minimum or Maximum measurement.
Pythagoras
measurements:

Makita LD080PI Specifications

General

Product color	Black, Blue
Memory function	Yes
Electronic compass	-
Display number of lines	3 lines
Distance measuring units	cm, m, mm
Number of memory records	20
International Protection (IP) code	IP54
Accuracy	1.5 mm
Wavelength	635 nm
Laser class	2
Sensor tilt angle	180 °
Maximum measurement distance	80 m
Minimum measurement distance	0.05 m
Battery type	AAA
Battery life (measurements)	5000

Weight and Dimensions

Depth	32 mm
Width	57 mm
Height	117 mm
Weight	140 g
