Makita LD080PI User Manual

Makita LD080PI
Instrument Set-up
3
EN
Display
Area /
Volume
Units
Stake out
Indirect height
Circumfer-
ence
Measuring
reference
2nd result
Battery
Angle
Wall area
Addition /
Subtraction
Timer
Memory
Pythagoras
Horizontal
measurement
Min/Max
Measuring
Main line
Insert batteries
i
To ensure a reli-
able use, do not
use zinc-carbon
batteries.
Change batter-
ies when battery
symbol is flash-
ing.

Makita LD080PI Specifications

General

Product color	Black, Blue
Memory function	Yes
Electronic compass	-
Display number of lines	3 lines
Distance measuring units	cm, m, mm
Number of memory records	20
International Protection (IP) code	IP54
Accuracy	1.5 mm
Wavelength	635 nm
Laser class	2
Sensor tilt angle	180 °
Maximum measurement distance	80 m
Minimum measurement distance	0.05 m
Battery type	AAA
Battery life (measurements)	5000

Weight and Dimensions

Depth	32 mm
Width	57 mm
Height	117 mm
Weight	140 g
