Identification of the Engine
24
Carefully read the Assembly Instructions before starting any work!
This is especially valid for the chapter on General Safety Instructions
and the safety instructions in each of the chapters.
3.1 Explanation of the Motor-Nr./Engine-No. (Engine Identification Number)
Motor-Nr./Engine-No. Class identifier
(assignment)
711 Model number according to index of model codes
1234 Day of assembly (plant internal)
547 Assembly order (sequence number on day of assembly)
3.2 Explanation of Model Designation
Model designation Declaration Example
E Fuel type Natural gas (or biogas)
08 Figure + 100 108 mm bore
3 Stroke figure (rounded) 125 mm stroke
4 / 6 Number of cylinders 4, 6 cylinders
L Charging With charger and
intercooling
E Installation engine Installation engine for power
generation plants
202 / 302 Model designation identification 202 = Development number
302 = Development number
312 = Development number
322 = Development number
