Do not mix up the hose connections; the inlet and outlet connections of the
heat exchangers are marked with arrows;
Ensure that the connections are sealed adequately;
To ensure free removal of the condensate, ensure that the listed diameters
for the condensate removal lines are not reduced!
Ensure that the connections are sealed adequately by noting the following:
Borosilicate glass heat exchangers with connections GL18-6 respectively GL25-12 (standard)
• Before assembly, check the GL coupling rings to see if the PTFE/silicon locking rings have been
damaged.
• The sealing rings should be installed with the PTFE side facing the medium.
PVDF- resp. stainless steel heat exchangers with G1/4“I resp. G3/8“I
• The correspondingly dimensioned tube respectively hose couplings with threaded connections
have to be screwed in with PTFE thread sealing tape.
• To grant a functional and unproblematic mounting we recommend to use union pieces with taper
pipe thread type R according to DIN 2999/1 in connection with suitable sealing tape.
When fixing the connectors in the PVDF respectively stainless steel heat
exchanger hold up with a wrench at the pane of the bolt head!
Option: stainless steel heat exchanger with NPT
• The heat exchangers with NPT threaded connectors are marked with circulated notches.
• In order to ensure the tightness of the connections, the NPT thread must be screwed in with
sealant or fixed with adhesive.
In the standard configuration, the tubes for removal of condensate are connected directly to the heat
exchangers. These protrude with the GL25-12 tube connectors (standard, Borosilicate glass heat
exchanger) respectively with G3/8” (standard) thread joint PVDF or stainless steel heat exchanger
above the base plate of the cooler casing (fig.2).
Condensate removal is done by customer according to the type of operation with:
• peristaltic pump(s) type SR25.2 implemented optionally in the cooler housing,
• external mounted condensate vessel(s) with manually emptying respectively,
• automatic float-type condensate traps type AD-... (only for over-pressure operation).
Stainless steel heat exchangers with G3/8” thread joint can be directly fitted
up with the float-type condensate trap AD-SS by means of a thread adapter
part number FF 11000 (1/2” NPT to G3/8”i). By this wall mounting and tubing
of the AD-SS unit isn’t necessary!
