www.mc-techgroup.com ECM | 1.01.00 19
1 Pump head (outside the cooler housing) 2 Cooler front panel
3 Recommended monting distance 4 Pump motor (inside the cooler housing)
Figure 6 SR25.2: Mounting distance between front panel and pump motor
For mounting instructions, see the SR25.2 instruction manual. The
manual is available on our website www.mc-techgroup.com.
16.3.2 CHANGE OF THE PUMP TUBE
Aggressive condensate is possible !
Wear protective glasses and proper protective clothing during
disassembly, repair or cleaning!
If you send back the peristaltic pump to the M&C service for repair,
please let us know what kind of condensate has been pumped.
Before sending the pump back clean all parts from dangerous or highly
aggressive contaminants.
