M&C ECM Series - 20 Appendix; Figure 9 Dependency of Gas Outlet Dew Point at a Gas Inlet Point of 60 °C [140 °F]

24 ECM | 1.01.00 www.mc-techgroup.com
20 APPENDIX
• Dependency of gas outlet dew point at a gas inlet point of 60 C [140 °F]
• Circuit diagram ECM Drawing No.: 2456-5.01.0
• Compressor connection
• Certificate of compliance
Further product documentation can be seen and downloaded from our home page:
www.mc-techgroup.com
• Threaded couplings for ‘GL’ glass connections
Document: 11.5
• Instruction manual peristaltic pump SR25
• Automatic liquid drain AD-SS
Document: 6.13M
• Automatic liquid drain AD-P
Document: 6.12
• Condensate vessel TG, TK
Document: 6.14
Figure 9 Dependency of gas outlet dew point at a gas inlet point of 60 °C [140 °F]
3
4
5
6
7
8
9
10
0 50 100 150 200 250
Outlet dew point in
°C
Gas flow Nl/h
ECM-2G
ECM-1G
