8 TECHNICAL DATA
8.1 FOR BASIC COOLER ECM WITHOUT HEAT EXCHANGER
Gas cooler series EC

Version ECM-1
Version ECM-2
Part No.
02 K 7500 (a)**
02 K 7510 (a)**
Number of heat exchanger
possibility
prepared for 1 stream
prepared for 2 streams
Sample outlet dew point
range of adjustment: +2 °C ..... +7 °C [35.6 °F …44.6 °F], factory
setting: +5 °C [41 °F]
Dew point stability
at const. conditions: < ±0.1 °C [±0.18 °F]
Sample inlet temperature
***max. +180 °C [356 °F]
Sample inlet dew point
***max. +80 °C [176 °F]
Gas flow rate
***max. 250 l/h
***max. 2x150 l/h
Ambient temperature
+10 °C to +50 °C [50 °F to 122 °F]
Storage temperature
-20 to +60 °C [~-4 °F to 140 °F]
Total cooling capacity
40 W at 10 °C – 50 °C [50 °F to 122 °F] ambient temperature
Ready for working
< 15 min
Power consumption
max. 200 VA (start up current at 230 V=2.5 A; at 120 V=4.5 A)
Main power connection
240 V/120 V, 50 Hz / 60 Hz (a) :-15 % / +10 %
Electrical connections
terminals: 6-12 mm , cable gland: 2 x M20 x 1,5
Status alarm
1 free configurable status alarm with 2 potential free change-over
contacts, alarm point: < 2°C [35.6 °F] and > 8 °C [46.4 °F]
contact rating 250 VAC, 2 A; 500 VA; 50 W
Electrical safety
EN
EN 61010
CAN/CSA-C22.2 No.61010.1-04
UL Std. No. 61010-1(2 Edition)
System of protection
IP20 (EN 60529)
Case colour
RAL 9003
Method of mounting
wall mounting
Dimensions
Weight
270 x 270 x 316 mm [10.63” x 10.63” x 12.44”] (W x H x D)
12 kg [26.46 lbs] /13.5 kg [29.76 lbs] (version: 230 V / 115 V)
** Option
*** Maximum values in technical data must be rated in consideration of total cooling capacity at 25 °C [77 °F] ambient
temperature and an outlet dew point of 5 °C [41 °F].
