M&R Printing Equipment, Inc. - Glen Ellyn, Illinois

Specifications

A clean, moisture free compressed air supply is essential for the contin-

ued operation of the M&R Challenger Series II press. We strongly recom-

mend that a refrigerated air chiller be installed in the compressed air sup-

ply line to the Challenger Series II press to prevent moisture damage to

pneumatic seals, valves and air cylinders used in the operation of the print

carriage (See diagram above). Failure to use a refrigerated compressed air

chiller with this equipment may void the warranty for pneumatic compo-

nents such as air cylinders, valves and seals.

Figure 2 Typical Multiple Unit (Loop) Compressor-Chiller Layout

CAUTION!
