M&R CHALLENGER II Series User Manual

Kebco Frequency Drive Error List
M&R Printing Equipment, Inc. - Glen Ellyn, Illinois
131
Display
Plaintext Combivis Value Meaning
E.SET
ERROR set
39
Error: Set selection: It has been attempted to select a locked
parameter set.
E.PRF
ERROR prot. rot. for.
46
Error: Locked direction of rotation clockwise.
E.PRR
ERROR prot. rot. rev.
47
Error: Locked direction of rotation counter-clockwise
E. PUCI
E. power unit code invalid 49 Error: during the initialization the power circuit could not be rec-
ognized or was identified as invalid.
E.PUCH
ERROR power unit
changed
50
Error: Power circuit identification was changed; with a valid
power circuit this error can be reset by writing to SY.3. If the
value displayed in SY.2 is written, only the power-circuit depen-
dent parameters are reinitialized. If any other value is written,
then the default set is loaded.
E.DRI
ERROR driver relay
51
Error: Driver relay. Relay for driver voltage on power circuit has
not picked up although control release was given.
E.HYB
ERROR hybrid
52
Error: Invalid encoder interface identifier
E.iED
ERROR input error detec-
tion
53
Error: Hardware error during the start/stop measurement.
E.CO1
ERROR counter overrun 1
54 Error: Counter overflow encoder channel 1
E.BR
ERROR brake
56
Error: This error can occur in the case of switched on brake con-
trol, if the load is below the minimum load level at start up or the
absence of an engine phase was detected.
E.INI
ERROR initialization MFC
57
Error: MFC not booted
E.OS
ERROR over speed
58 Error: Real speed is larger than the max. Output speed.
E.CO2
ERROR counter overrun 2
55 Error: Counter overflow encoder channel 2
FAcc
forward acceleration
64 Forward acceleration
FdEc
forward deceleration
65 Forward deceleration
Fcon
forward constant
66 Forward constant run
rAcc
reverse acceleration
67 Reverse acceleration
rdEc
reverse deceleration
68 Reverse deceleration
rcon
reverse constant
69 Reverse constant run
LS
low speed
70 No direction of rotation preset
SLL
stall
71 Constant current limit active
LAS
LA stop
72 Acceleration stop active
LdS
Ld stop
73 Deceleration stop active
SSF
speed search
74 Speed search function active
dcb
DC brake
75 DC-brake active
bbL
base block
76 Power modules for motor de-excitation locked
dLS
low speed/DC brake
77 No direction of rotation preset after DC-brake
POFF
power off
78
Power-Off-function active
StOP
quick stop
79 Quick stop active
E.ccd
ERROR calculation drive
60 Error: During the automatic motor stator resistance measure-
ment.
E.HYBc
ERROR hybrid changed
59 Error: Encoder interface identifier has changed, it must be con-
firmed over ec.0 or ec.10.
