CHECK Overload alarm
t
IMPORTANT
t
Refer to the platform repair manual if the overload alarm is not correctly calibrated.
NOTE: The platform is in transport position. The turntable, the basket and the jib (150AETJ3D (150AETJC3D)) are in neutral
position. The jib is completely lowered.
NOTE: The turntable cover is removed.
- Switch the platform on.
- Place a uniformly distributed 220kg weight in the basket.
Result:
• The audible alarm should sound continuously.
• The overload alarm indicator lamp should flash.
- Try to activate all the functions one by one using the ground level control panel.
Result:
• It should not be possible to activate any of the functions.
- Remove 20kg to obtain a load of 200kg in the basket.
Result:
• The audible alarm should stop.
• The overload alarm indicator lamp should go out.
- Try to activate all the functions one by one using the ground level control panel.
Result:
• It should be possible to activate all the functions.
- Place the platform in transport position. Put the turntable, the basket and the jib (150AETJ3D (150AETJC3D)) in neutral
position. Lower the jib completely.
- Get into the basket.
Result:
• The audible alarm should sound continuously.
• The overload/fault alarm indicator lamp should flash.
- Try to activate all the functions one by one using the control panel in the basket.
Result:
• It should not be possible to activate any of the functions.
- Get out of the basket.
Result:
• The audible alarm should stop.
• The overload/fault alarm indicator lamp should go out.
- Remove the whole load from the basket.
3 - 33
647536 (26/11/2020) 150 AETJ/AETJ 3D - 150 AETJ C/AETJ C 3D - 170 AETJ L
