Manitou Mezzer Pro Service Manual

10
MEZZER SERVICE MANUAL
AIR SPRING SERVICE
5
6
Remove Air Spring Assembly, clean
with isopropyl, Inspect seal for
damage. Replace air piston seal
(141-36713-K027). If Travel
change is need see page 26
before moving on.
Once the air spring assembly is
removed clean the inside of the
stanchion with isopropyl alcohol
and a lint free towel (Be careful
to not scratch the inner surface of
the stanchion). Inspect the inside
and outside of the stanchion for
scratches or other damage.
4
Invert the fork and use Manitou
cassette tool with adjustable
wrench to unthread the air spring
assembly from the stanchion.OR
depress valve on end of comp-rod
with 2mm hex and stroke rod to
bottom. Slide standard cassette
lock-ring tool over threaded
adapter and unthread the air spring
assembly from the stanchion.

Manitou Mezzer Pro Specifications

General

Travel	140mm, 150mm, 160mm, 170mm, 180mm
Wheel Size Compatibility	27.5", 29"
Spring Type	Air
Axle	15x110mm Boost
Steerer Tube	1.5" Tapered
Intended Use	Enduro
Adjustments	High Speed Compression, Low Speed Compression, Rebound, Air Pressure
Offset	44mm (27.5"), 51mm (29")
