Manitou Mezzer Pro Service Manual

6
MEZZER SERVICE MANUAL
CASTING REMOVAL & SERVICE
1
Remove rebound knob using a 2mm
Hex wrench.
Note: Be sure to hold the knob
still while removing the screw. The
damper adjuster may be damaged
if the knob is over torqued.
Hold lock-nut with 14mm box end
wrench. Insert a 8mm Hex wrench
into the end of the rebound rod and
loosen clockwise until rebound rod
disengages from the lock-nut.
2
3
Unscrew air cap and attach shock
pump. Depress pressure bleed
button until pump reads “Zero”.
Depress Schrader Valve a few times
with 2mm hex wrench to ensure all
air is released.
Manitou recommends a full service anytime the
casting is removed. If the fork is new and only a
travel change is needed, follow instructions 1-4
then skip to Page 31 for Travel change instructions.
Return to page 19 for casting install.

Manitou Mezzer Pro Specifications

General

Travel	140mm, 150mm, 160mm, 170mm, 180mm
Wheel Size Compatibility	27.5", 29"
Spring Type	Air
Axle	15x110mm Boost
Steerer Tube	1.5" Tapered
Intended Use	Enduro
Adjustments	High Speed Compression, Low Speed Compression, Rebound, Air Pressure
Offset	44mm (27.5"), 51mm (29")
