INTERRUTTORE ONOFF ARIA
CONDIZIONATA
Questo interruttore identica (2,
23)
il controllo che aziona il condizionatore
dell’aria.
Sull’interruttore (2,
23) il led si accende
(1,
23) per indicare che la funzione è
attiva.
COMANDO VENTILAZIONE
ARIA CONDIZIONATA
Questo interruttore identica (2,
24)
il controllo che aziona il condizionatore
dell’aria.
L’interruttore ha tre posizioni:
- ventilazione minima (2a,
24),
- ventilazione media (2b,
24),
- ventilazione massima (2c,
24).
Sull’interruttore (2,
24) il led si accende
(1,
24) per indicare che la funzione è
attiva.
INTERRUTTORE COMANDO OPTIONAL
BENNA
Questo interruttore identica (2,
25) il
controllo per il funzionamento della benna
multiuso.
Sull’interruttore (2,
25) il led si accende
(1,
25) per indicare che la funzione è
attiva.
AIR CONDITIONING ONOFF SWITCH
This switch (2,
23) identies the control
that operates the air conditioning unit.
On the switch (2,
23) the led light up
(1,
23) to indicate that the function is
active.
AIR CONDITIONING VENTILATION
CONTROL
This switch (2,
24) identies the control
which activates the fan and circulates air at
a speed selected by the user.
The switch has three positions:
- minimum ventilation (2a,
24),
- medium ventilation (2b,
24),
- maximum ventilation (2c,
24).
On the switch (2,
24) the led light up
(1,
24) to indicate that the function is
active.
MULTIPURPOSE BUCKET CONTROL
SWITCH
This switch (2,
25) identies the control
for operation of the multi-purpose bucket.
On the switch (2,
25) the led light up
(1,
25) to indicate that the function is
active.
1
2
3.23
1
2
3.24
1
3.25
2a
2b
2c
2
INTERRUPTEUR ONOFF DE
CLIMATISATION
Cet interrupteur correspond (2,
23) au
contrôle qui actionne le climatiseur d'air.
Sur l'interrupteur (2,
23) la diode s'allume
(1,
23) pour indiquer que la fonction est
active.
COMMANDE DE VENTILATION D'AIR
CLIMATISÉ
Cet interrupteur correspond (2,
24) au
contrôle qui actionne le climatiseur d'air.
L'interrupteur a trois positions :
- ventilation minimale (2a,
24),
- ventilation moyenne (2b,
24),
- ventilation maximale (2c,
24).
Sur l'interrupteur (2,
24) la diode s'allume
(1,
24) pour indiquer que la fonction est
active.
INTERRUPTEUR DE COMMANDE DE
BENNE EN OPTION
Cet interrupteur correspond (2,
25) au
contrôle du fonctionnement de la benne à
usages multiples.
Sur l'interrupteur (2,
25) la diode s'allume
(1,
25) pour indiquer que la fonction est
active.
