Manitou MSI 40 - Sling the Lift Truck

3 - 34
AB
H4/3
H4/1
H4/2
H4 - SLING THE LIFT TRUCK
- Take into account the position of the lift truck gravity center for lifting (Fig. H4/1).
- Place the hooks in the fastening points provided (Fig. H4/2 and H4/3).
A = 1056 mm B = 1019 mm (MSI 40)
A = 1169 mm B = 906 mm (MSI 50)
