Manitou MT 1435 EASY 75D ST3B S1 User Manual

2 - 33
SEAT BACK-REST ANGLE ADJUSTMENT (FIG. C)
The back-rest angle of the seat may be adjusted to suit the individual.
- Press the left-hand button while pushing on the seat or relaxing pressure on the
seat to find a comfortable position.
SEAT DEPTH ADJUSTMENT (FIG. D)
The depth of the seat may be adjusted to suit the individual.
- Press the right-hand button while raising or lowering the seat to find the desired
position.
EXTENDING THE HEAD-REST (FIG. E)
- The height of the back-rest can be adjusted by pulling it upwards (the notches will
click) up to the stop.
- The head-rest can be removed by applying sufficient pressure to pull it off the stop.
LUMBAR ADJUSTMENT (FIG. F)
This increases the comfort of the seat and the driver’s freedom of movement.
- Turn the handle either left or right to adjust the height or depth of the lumbar
support.
ADJUSTMENT OF THE ANGLE OF THE BACK-REST (FIG. G)

IMPORTANT

If you do not support the back-rest when making adjustments, it swings completely forwards.
- Support the back-rest, pull the lever and position the back-rest to find the desired
position.
LONGITUDINAL ADJUSTMENT (FIG. H)
- Adjust the locking lever until you reach the position required. This then locks and
the seat will not shift into another position.
MAINTENANCE (FIG. I)

IMPORTANT

A moving backrest increases the risk of an accident!
Dirt may adversely affect the correct functioning of the seat. For this reason, make sure
your seat is always clean.
- To clean or change the cushions, simply remove them from the seat frame.
- Avoid wetting the cushion fabric when cleaning it. Firstly check the resistance of
the fabric on a small hidden area before using any fabric or plastic cleaner.
C
D
E
F
IHG
647563 (22/08/2017) MT 1435/1440/1840 EASY 75D ST3B S1
