Manitowoc 14000 Service And Maintenance Manual

Reference Only
Manitowoc Published 09-10-14, Control # 065-24 3-15
14000 SERVICE MANUAL ELECTRIC SYSTEM
3
44-C Ground
Drum 4 - Pump 4 Ground
44-D DO-12
Drum 4 - Pump 4 0 Volts Off; 24 Volts On CAN23-2-8
44-E Ground
Drum 4 Motor Control Ground
44-F DO-13
Drum 4 Motor Control See Table 3-2 for Values CAN23-2-16
44-G Ground
Drum 4 Brake Release Ground
44-H DO-14
Drum 4 Brake Release 0 Volts Off; 24 Volts On CAN23-2-32
44-J Ground
Swing - Pump 6 Ground
44-K Ground
Left Travel/Drum 3 - Pump 3 Ground
44-L Ground
Left Travel/Drum 3 - Pump 3 Ground
44-M DO-17
Left Travel/Drum 3 - Pump 3 0 Volts Off; 24 Volts On CAN23-3-1
44-N Ground
Swing - Pump 6 Ground
44-P DO-16
Swing - Pump 6 0 Volts Off; 24 Volts On CAN23-2-128
44-R DO-15
Swing - Pump 6 0 Volts Off; 24 Volts On CAN23-2-64
44-S DO-18
Left Travel/Drum 3 - Pump 3 0 Volts Off; 24 Volts On CAN23-3-2
44-T Ground
Right Travel - Pump 1 Ground
44-U DO-19
Right Travel - Pump 1 0 Volts Off; 24 Volts On CAN23-3-4
44-V Ground
Right Travel - Pump 1 Ground
44-W DO-20
Right Travel - Pump 1 0 Volts Off; 24 Volts On CAN23-3-8
44-X Ground
Drum 2 - Pump 5 Ground
44-Z DO-21
Drum 2 - Pump 5 0 Volts Off; 24 Volts On CAN23-3-16
44-a Ground
Drum 2 - Pump 5 Ground
44-b DO-22
Drum 2 - Pump 5 0 Volts Off; 24 Volts On CAN23-3-32
44-c Ground
Drum 1 - Pump 2 Ground
44-d DO-23
Drum 1 - Pump 2 0 Volts Off; 24 Volts On CAN23-3-64
44-e Ground
Drum 1 - Pump 2 Ground
44-f DO-24
Drum 1 - Pump 2 0 Volts Off; 24 Volts On CAN23-3-128
44-g Ground
Jumper to Node Select 4 Ground
44-k NS-3
Node Select 3 Jumper to Ground 0 Volts (With Jumper)
44-n 24 Volts
Drum 4 Speed Sensor 24 Volts Nominal
44-p EC3A
Drum 4 Speed Sensor
1.2 or 3.2 Volts Not Moving;
2.2 Volts Moving
CAN42-3
2
44-r Ground
Drum 4 Speed Sensor Ground
44-s EC3B
Drum 4 Speed Sensor
1.2 or 3.2 Volts Not Moving;
2.2 Volts Moving
CAN42-3
2
J6/W46 Receptacle – Sensors, Pressure Senders, Alarms, and Auto Lube
46-A Ground
Crawler Track/Swing Bearing Auto Lube Ground
46-B DO-7
Swing Bearing Auto Lube 0 Volts Off; 24 Volts On CAN23-1-64
46-C Ground
Gantry Maximum Angle Limit
Hydraulic Fluid Level
Ground
46-D DO-8
Hydraulic Fluid Level 0 Volts Off; 24 Volts On CAN23-1-128
46-E Ground
Left Side RCL Capacity Alarm/
Jumper to Node Select 3
Ground
46-F DO-9
Crawler Track Automatic Lubrication 0 Volts Off; 24 Volts On CAN23-2-1
46-G Ground
Hydraulic Fluid Temperature Sensor Ground
46-H DO-10
Left Side RCL Capacity Alarm 0 Volts Off; 24 Volts On CAN23-2-2
46-M NS-3
Node Select 3 Jumper to Ground 0 Volts (With Jumper)
