ELECTRIC SYSTEM 14000 SERVICE MANUAL
3-16
Published 09-10-14, Control # 065-24
46-P DI-7
Gantry Maximum Angle Limit 0 Volts Off; 24 Volts On CAN40-1-64
46-R 24 Volts
Gantry Maximum Angle Limit 24 Volts Nominal
46-S 24 Volts
Hydraulic Vacuum Set Point 24 Volts Nominal
46-T 24 Volts
Left Travel Pressure Sender 24 Volts Nominal
46-U Ground
Left Travel Pressure Sender Ground
46-V 5 Volt
Drum 1 & 2 Motor Speed Sensor Variable 0 to 5 Volts
46-W Ground
Right Travel Pressure Sender Ground
46-X 24 Volts
Hydraulic Fluid Level/Temperature Sensor 24 Volts Nominal
46-Z Ground
Drum 2 Motor Speed Sensor Ground
46-a AI-9
Hydraulic Vacuum Set Point 0 Volts Off; 24 Volts On CAN14-2-16
46-c AI-11
Hydraulic Return Filter Alarm 0 Volts Off; 24 Volts On CAN14-2-64
46-e AI-13
Left Travel Pressure Sender
1 Volt at 0 psi,
5 Volts at 7,000 psi
CAN15-2
1
46-f AI-14
Hydraulic Fluid Temperature Sensor Variable 1 to 4 Volts
CAN15-4
1
46-g 24 Volts
Right Travel Pressure Sender 24 Volts Nominal
46-h AI-15
Right Travel Pressure Sender
1 Volt at 0 psi,
5 Volts at 7,000 psi
CAN15-6
1
46-j Ground
Drum 1 Motor Speed Sensor Ground
46-k AI-16
Hydraulic Fluid Level Variable 0 to 24 Volts
CAN15-8
1
46-m 24 Volts
Hydraulic Return Filter Alarm 24 Volts Nominal
46-n EC1A
Drum 1 Motor Speed Sensor
1.2 or 3.2 Volts Not Moving;
2.2 Volts Moving
CAN41-1
2
46-p EC1B
Drum 1 Motor Speed Sensor
1.2 or 3.2 Volts Not Moving;
2.2 Volts Moving
CAN41-1
2
46-r EC-2A
Drum 2 Motor Speed Sensor
1.2 or 3.2 Volts Not Moving;
2.2 Volts Moving
CAN41-3
2
46-s EC-2B
Drum 2 Motor Speed Sensor
1.2 or 3.2 Volts Not Moving;
2.2 Volts Moving
CAN41-3
2
1
Lower four bits are the most significant bit of the analog value.
2
The number in the indicated bank should increase with device rotation and decrease with rotation in opposite direction.
