Manitowoc 14000 Service And Maintenance Manual

Reference Only
ELECTRIC SYSTEM 14000 SERVICE MANUAL
3-42
Published 09-10-14, Control # 065-24
Table 3-7 Digital Output Disable
CAN
Packet
Number
Item Description
30-1-1 Rated Capacity Indicator/Limiter Beacon
30-1-2 Handle 4 Rotation Indicator
30-1-4 Handle 2 Rotation Indicator
30-1-8 Cooler Fan Pump
30-1-32 Handle 3 Rotation Indicator
30-1-64 Handle 1 Rotation Indicator
30-1-128 Seat Switch and Left Handle Center Switch
30-2-1 Right Console
30-2-8 Right Console and Handle Center Switch
30-2-16 Engine Coolant Temperature
30-2-128 Engine Oil Pressure Gauge
30-3-32 Rated Capacity Indicator/Limiter Alarm
30-3-64 Foot Throttle
30-3-128 System Fault Alarm
31-1-1 Drum 1 (Front Drum) Motor Control
31-1-2 Drum 1 (Front Drum) Brake Solenoid=
31-1-4 Gantry Cylinders Retract Switch
31-1-8 Gantry Cylinders Extend Switch
31-1-16 Mast Cylinders Retract Switch
31-1-32 Mast Cylinders Extend Switch
31-1-64 Drum 1 (Front Drum) Free Fall Pulse
31-1-128 Drum 2 (Rear Drum) Free Fall Pulse
31-2-1 Free Fall and Rigging Winch Enable
31-2-4 Travel Brake
31-2-8 Travel Motor
31-2-16 Swing Brake
31-2-32 Drum 3 (Auxiliary/Luffing) Diverter
31-2-64 Drum 3 (Auxiliary/Luffing) Pawl - In
31-2-128 Boom Hinge Pins Disengage
31-3-1 Drum 4 (Boom Hoist) Pawl - In
31-3-2 Back Hitch Pins Disengage
31-3-4 Cab Tilt Down Switch
31-3-8 Cab Tilt Up Switch
31-3-16 Drum 3 (Auxiliary/Luffing) Pawl - Out
31-3-32 Drum 4 (Boom Hoist) Pawl - Out
31-3-64 Drum 3 (Auxiliary/Luffing) Brake
31-3-128 Drum 3 (Auxiliary/Luffing) Motor
33-1-1 Rigging Winch - Haul In
33-1-2 Rigging Winch - Pay Out
33-1-4 Drum 2 (Rear Drum) Motor
33-1-8 Drum 2 (Rear Drum) Brake
33-1-16 Rigging Winch Brake
33-1-32 Right Side Swing/Travel Alarm
33-1-64 Swing Auto Lubrication
33-1-128 Hydraulic Fluid Level
33-2-1 Travel Auto Lubrication
33-2-2 Rated Capacity Indicator/Limiter Alarm
33-2-4 Drum 4 (Boom Hoist) Pump - Raise
33-2-8 Drum 4 (Boom Hoist) Pump - Lower
33-2-16 Drum 4 (Boom Hoist) Motor
33-2-32 Drum 4 (Boom Hoist) Brake
33-2-64 Swing Pump - Right
33-2-128 Swing Pump - Left
33-3-1 Left Track Pump - Forward
33-3-2 Left Track Pump - Reverse
33-3-4 Right Track Pump - Reverse
33-3-8 Right Track Pump - Forward
33-3-16 Drum 2 (Rear Drum) Pump - Lower
33-3-32 Drum 2 (Rear Drum) Pump - Raise
33-3-64 Drum 1 (Front Drum) Pump - Lower
33-3-128 Drum 1 (Front Drum) Pump - Raise
