2 For Your Safety
Operating and Installation Instructions UL 11
Risk / hazard Where and in which situations will the
risk/hazard exist?
What to do / safety equipment
Crush hazard if the unit
topples over
 Whenever moving the units across
uneven surfaces or after bumping into
an obstacle
 Whenever the connections are not
disconnected before lifting
 Whenever the unit is not positioned
correctly
 Whenever the supporting surface is
not stable and even
 Secure the units so that they cannot
topple over
 Use suitable equipment and assembly
aids to transport the units
 Set up the units on an even and stable
supporting surface
 Disconnect the connections
 Place the unit on the locating pins
correctly and screw it in place
Safety device:
 Wall anchoring kit (optional)
 Locating pins and screw joints
 Marine model: Feet that can be
screwed onto the floor
 Whenever the top unit is loaded with a
lot of weight
 When moving the stacking kit
 When placing the unit on its back
Exercise caution when performing
maintenance work
Contact with cleaning
agents
When cleaning agent tubes are dam-
aged or cut by sharp components
Follow the installation sequence in the
instructions
Risk of scalding
Whenever opening the bottom unit’s
door
Exercise caution when performing
maintenance work
Fall hazard as a result of
wet floors
When cleaning agent tubes are dam-
aged or cut by sharp components
Check the way the cleaning agent tubes
are routed
Pinch point hazard for
hands and fingers
When installing the side panels
 Exercise caution when performing
maintenance work
 Wear the required personal protective
equipment
Risk of burns posed by hot
surfaces
 On the exhaust duct
 On the exhaust ducts
 Everywhere on the inside
 On the outside of the unit door
 Wear the required personal protective
equipment
 Let the units cool down before per-
forming maintenance
Cut hazard
 When knocking out the perforated
knockout on the front plate
 When knocking out the perforated
knockout on the top unit’s bottom
 Exercise caution when performing
maintenance work
 Wear the required personal protective
equipment
 Remove the knockout as indicated in
the instructions and deburr the corre-
sponding edges
