6.10 6.20 10.10 10.20 12.20 20.10 20.20
Steam power [kW] 9.1 18.1 18.1 27.2 31.6 31.6 40.2
Motor power [kW] 0.35 0.35 0.35 0.35 0.35 0.7 0.7
Rated current [A] 15.9 28.1 28.1 48.7 48.7 56.2 97.3
Fuse [A] 16 35 35 50 50 63 100
Recommended conductor cross-
section for wires laid uncovered in
air up to 5 m in length.
[mm
2
]
5G4 5G6 5G6 5G16 5G16 5G16 5G35
Recommended residual-current de‐
vice
Type B/F B/F B/F B/F B/F B/F B/F
3~ 440V 60 Hz
Rated power consumption [kW] 9.2 16.3 16.3 28.2 28.2 32.6 56.3
Convection power [kW] 8.8 15.9 15.9 27.8 27.8 31.8 55.5
Steam power [kW] 7.6 15.1 15.1 22.7 26.3 26.3 33.6
Motor power [kW] 0.35 0.35 0.35 0.35 0.35 0.7 0.7
Rated current [A] 12.1 21.4 21.4 37.0 37.0 42.8 73.9
Fuse [A] 16 25 25 50 50 50 100
Recommended conductor cross-
section for wires laid uncovered in
air up to 5 m in length.
[mm
2
]
4G4 4G6 4G6 4G16 4G16 4G16 4G35
Recommended residual-current de‐
vice
Type B/F B/F B/F B/F B/F B/F B/F
3~ 480V 60 Hz
Rated power consumption [kW] 10.9 19.3 19.3 33.4 33.4 38.6 66.8
Convection power [kW] 10.5 18.9 18.9 33.0 33.0 37.8 66.1
Steam power [kW] 9.0 18.0 18.0 27.0 31.3 31.3 39.9
Motor power [kW] 0.35 0.35 0.35 0.35 0.35 0.7 0.7
Rated current [A] 13.1 23.3 23.3 40.3 40.3 46.5 80.5
Fuse [A] 16 25 25 50 50 50 100
Recommended conductor cross-
section for wires laid uncovered in
air up to 5 m in length.
[mm
2
]
4G4 4G6 4G6 4G16 4G16 4G16 4G35
Recommended residual-current de‐
vice
Type B/F B/F B/F B/F B/F B/F B/F
Convotherm 4 ES (single-phase FC)
6.10 6.20 10.10 10.20 12.20 20.10 20.20
3N~ 400V 50/60Hz (3/N/PE)
Rated power consumption [kW] 11.0 19.5 19.5 33.7 33.7 38.9 67.3
Convection power [kW] 10.6 19.1 19.1 33.3 33.3 38.1 66.5
Motor power [kW] 0.35 0.35 0.35 0.35 0.35 0.7 0.7
Rated current [A] 15.9 28.1 28.1 48.7 48.7 56.2 97.3
Fuse [A] 16 35 35 50 50 63 100
Recommended conductor cross-
section for wires laid uncovered in
air up to 5 m in length.
[mm
2
]
5G4 5G6 5G6 5G16 5G16 5G16 5G35
Recommended residual-current de‐
vice
Type A A A A A A A
Optional residual-current device Type B/F B/F B/F B/F B/F B/F B/F
3~ 230V 50/60Hz (3/PE)
Rated power consumption [kW] 10.9 19.3 19.3 33.4 33.4 38.2 66.4
