6.1.4 Connection to an energy optimization system (electric appliances only)
Purpose of an energy optimization system
You can connect the combi steamer to an energy optimization system (e.g. SICOTRONIC). An energy
optimization system smooths out peaks in power consumption that occur during operation of your ap‐
pliances, and can thereby help to reduce your energy costs.
Configuring an energy optimization system
The energy optimization system must be configured as follows:
The continuous switch-on time for the combi steamer must be set to at least 8 minutes to be certain
that the target cooking temperature is reached.
The energy optimization system must not disconnect the power for longer than 30 seconds be‐
cause the cooking result cannot be guaranteed for a longer interruption in the power supply.
When connecting the system, refer to the circuit diagram and operating instructions of the energy opti‐
mization system.
Connecting an energy optimization system
The figure below shows a size 12.20 combi steamer as an example for all appliance sizes:
1.
Disconnect the energy optimization system and the combi
steamer from the power supply.
2.
Remove the side panel from the combi steamer in order
to access terminal block -X37 (2) on the electronic circuit
board (SIB) (1).
3.
Remove the wire link between the terminals (B) and (C)
on terminal block -X37 (2).
6 Installation
Installation manual 75
