6.10 6.20 10.10 10.20 12.20 20.10 20.20
Motor power [kW] 0.35 0.35 0.35 0.35 0.35 0.7 0.7
Rated current [A] 13.1 23.3 23.3 40.3 40.3 46.5 80.5
Fuse [A] 16 25 25 50 50 50 100
Recommended conductor cross-
section for wires laid uncovered in
air up to 5 m in length.
[mm
2
]
4G4 4G6 4G6 4G16 4G16 4G16 4G35
Recommended residual-current de‐
vice
Type B/F B/F B/F B/F B/F B/F B/F
Convotherm 4 GB
Electrical connected load rat‐
ings
6.10 6.20 10.10 10.20 12.20 20.10 20.20
1N~ 100V 50/60 Hz
Rated power consumption [kW] 0.6 0.6 0.6 0.6 0.6 1.1 1.1
Convection power [kW] 0.1 0.1 0.1 0.1 0.1 0.2 0.2
Steam power [kW] 0.1 0.1 0.1 0.1 0.1 0.1 0.1
Motor power [kW] 0.35 0.35 0.35 0.35 0.35 0.7 0.7
Rated current [A] 6.3 6.3 6.3 6.3 6.3 10.9 10.9
Fuse [A] 16 16 16 16 16 16 16
Recommended conductor
cross-section for wires laid un‐
covered in air up to 5 m in
length.
[mm
2
]
3G2.5 3G2.5 3G2.5 3G2.5 3G2.5 3G2.5 3G2.5
1N~ 230V 50/60 Hz
Rated power consumption [kW] 2.7 2.7 2.7 2.7 2.7 4.7 4.7
Convection power [kW] 0.1 0.1 0.1 0.1 0.1 0.2 0.2
Steam power [kW] 0.1 0.1 0.1 0.1 0.1 0.1 0.1
Motor power [kW] 0.35 0.35 0.35 0.35 0.35 0.7 0.7
Rated current [A] 2.7 2.7 2.7 2.7 2.7 4.7 4.7
Fuse [A] 16 16 16 16 16 16 16
Recommended conductor
cross-section for wires laid un‐
covered in air up to 5 m in
length.
[mm
2
]
3G2.5 3G2.5 3G2.5 3G2.5 3G2.5 3G2.5 3G2.5
Convotherm 4 GS
Electrical connected load rat‐
ings
6.10 6.20 10.10 10.20 12.20 20.10 20.20
1N~ 100V 50/60 Hz
Rated power consumption [kW] 0.5 0.5 0.5 0.5 0.5 1.0 1.0
Convection power [kW] 0.1 0.1 0.1 0.1 0.1 0.2 0.2
Motor power [kW] 0.35 0.35 0.35 0.35 0.35 0.7 0.7
Rated current [A] 5.2 5.2 5.2 5.2 5.2 9.8 9.8
Fuse [A] 16 16 16 16 16 16 16
Recommended conductor
cross-section for wires laid un‐
covered in air up to 5 m in
length.
[mm
2
]
3G2.5 3G2.5 3G2.5 3G2.5 3G2.5 3G2.5 3G2.5
9 Technical data
Installation manual 119
