Manitowoc Grove RT770E Service Maintenance Manual

4-11
Published 11/26/2014, Control # 447-05
RT770E SERVICE MANUAL BOOM
4
GROVE
Item Description
1 Base Section Weld
2 Tele-1 Weld
3 Tele 2 Weld
4 Tele 3 Weldment
5 Tele 4 Weld
6 Cylinder, Telescope
7 Shim-Base
8 Front Lower Wear Pad Base
9 Front Lower Wear Pad Base
10 Protection Strip G-Nr.3006000-
11 Upper Wear Pad Assy
12 Plate
13 Keeper Plate
14 Keeper Plate
15 Keeper Plate
16 F Washer 12 -St ISO 7089
17 L Washer 12 -Hrc44-51 Din 7980
18 Hex Nut M12 8 ISO 4032
19 HHCS M12x40 8.8 ISO 4017
20 HHCS M12x25 8.8 ISO 4017
21 HHCS M12x80 8.8 ISO 4014
22 Pat Bracket
23 HHCS M8x25 8.8 ISO 4017
24 F Washer 8 -St ISO 7089
25 L Washer 8 -Hrhrc44-51 Din 798
26 Hex Nut M8 8 ISO 4032
27 HHCS M20x60 8.8 ISO 4017
28 Hex Jam Nut M20 04 ISO 4035
29 Wedge S890 Ql
30 Bar S890 Ql
31 HHCS M24x115 10.9-Flz ISO 4014
32 Plate
33 F Washer 6 -St ISO 7089
34 Slot Pms M6x16 4.8 ISO 1580
35 SHCS 1/4-20uncx0.75 A574
36 SHCS 1/4-20uncx1 A574
37 Manifold, Tele Stage Selection
38 Tube Assy
39 Tube Assy
40 Pipe Clamp
41 Tube Assy
42 Tube Assy
43 SHCS M10x50 -10.9 ISO 10642
44 SHCS M10x35 8.8-A3c ISO 4762
45 SHCS M12x55 8.8-A3c ISO 4762
46 Male 90 Deg Elbow ORFS/BSPP
47 Pipe Clamp - 1/2””I.D.
48 Tube Assy
49 Tube Assy
50 Pipe Clamp
51 Male 90 Deg Elbow ORFS/BSPP
52 Tube Assy
53 Shim-Tele 1
54 Front Lower Wear Pad Tele 1
55 Front Lower Wear Pad Tele 1
56 Stop Block
57 Plate Dc03-A-M
58 HHCS M12x55 8.8 ISO 4017
59 Rear Upper Wear Pad
60 Trunnion Plate
61 F Washer 1-1/8”” Hard ASTM F-43
62 HHCS M30x55 10.9 ISO 4017
63 Retract Anchor Weld
64 Anchor Plate
65 Retract Cable Tele 3
66 Hex Nut M16 8 ISO 4032
67 F Washer 1/2”” Hard ASTM F-436
68 HHCS M12x30 10.9 ISO 4017
69 HHCS M12x40 10.9 ISO 4017
70 Spacer
71 Wear Pad Assy
72 L Washer 10 -Hrc44-51 Din 7980
73 Anchor Plate
74 F Washer 1-1/2”” Nar Ms
75 Hex Nut 1-1/2-6unc Sae-8
76 HHCS 1-1/2-6uncx14 G8
77 Pipe Union Sv-06l/Sw17 M12x1,
78 Thin Nut M12x1.5 5 Din 80705
79 Adapter 304-19509-1 M10x1/M10x
80 Elbow, Push-In 226-14123-3 Wek
81 Lubricant Hose L=280
82 Wear Pad
83 HHCS M10x20 SS ISO 4017
84 Plate Cover
85 HHCS M8x20 8.8 ISO 4017
86 O-Ring 0.75”” S.F.
87 O Ring 1””
88 O-Ring
89 Shim-Tele 2
90 Front Lower Wear Pad Tele 2
Item Description
