LUBRICATION RT770E
9-12
Published 11/26/2014, Control # 447-05
Item
Lube Point
Description
Figure
No.
Approved
Lubricant
Lube
Capacity
Lube Interval Application
Drive Train
20a
20b
a. Engine
Crankcase
b. Filter
Figure 9-3
EO-15W/40
Engine Oil
SAE 15W-40
T3 Engine -
6829003483
T4 Engine -
6829104182
18.9 L
(20 qt)
• Check level every 10
hours or daily
• Drain, fill and replace
filter every: 500 hours
(0-500 ppm sulfur fuel);
400 hours
(500-5000 ppm sulfur
fuel); 250 hours
(>5000 ppm sulfur fuel)
• Through fill cap to
FULL mark on
dipstick
• Filter located on
left side of frame
beneath radiator
21a
21b
a. Transmission,
Torque
Converter,
Dipstick
b. Filter
Figure 9-3
HYDO
Hydraulic Oil
6829006444
37.9 L
(40 qt)
• Check level every 10
hours or daily
• Drain and refill every
1000 hours or 6
months
• Change transmission
filter after first 50 and
100 hours of service,
then every 500 hours
thereafter
Through fill pipe to
FULL mark on
dipstick
NOTE:
• Check the transmission fluid level with engine running at 850 rpm idle and the converter oil at 83°C to 93°C (180°F to 200°F). Do
not attempt an oil level check with cold oil. To bring the oil temperature to this range, it is necessary to either work the crane or
stall the converter. Converter stall should be accomplished by engaging shift lever in forward high range with the brakes applied
and then accelerating the engine to half or three-quarter throttle. Hold the stall until the required converter temperature is
reached and stabilized. (Do not operate the converter at stall condition for longer than 30 seconds at one time. Shift to neutral for
15 seconds and repeat the procedure until the desired temperature is reached. Excessive temperature, i.e, 120°C (250°F)
maximum will cause damage to transmission clutches, fluid, converter and seals.)
• Drain the oil at 65°C to 93°C (150°F to 200°F).
• Transmission filters are located on the outside left hand frame in the area of the hydraulic oil cooler inside left hand engine cover.
• To add fluid:
a. Fill to FULL mark on dipstick
b. Run engine at 850 rpm to prime torque converter and lines
c. Check oil level with engine running at 850 rpm and converter oil at 82°C to 93°C (180°F to 200°F). Add oil to bring
oil level to FULL mark on dipstick.1
22
Engine Cooling
System and SCA
Levels
Figure 9-3
AFC 50/50
50/50 Blended
Fully
Formulated
Antifreeze
Coolant
6829101130
SCA
6829012858
37.9 L
40 qt
• Check coolant level
every 10 hours or daily
• Check SCA levels
every 500 hours or 3
months
• Check coolant for
contamination every
1000 hours or 6
months
See Service Manual
23
Coolant Strainer
(Cab Heater)
Figure 9-3 --- ---
Clean strainer screen
after first 100 hours and
every 2000 hours or 12
months intervals
thereafter.
Close shutoff valves.
Unscrew hex plug to
clean filter.
