24
Superstructure
12,9 m – 60,0 m, six section, Megaform
tm
style boom with Twin-lock
TM
boom
pinning system. Maximum tip height: 63,7 m. Eight nylatron sheaves mounted on
heavy duty tapered roller bearings with removable pin-type rope guards. Quick reeve
type boom nose.
11,0 m - 18,0 m bifold swingaway extension. Offsets at 0°, 20° and 40°.
Stows alongside base boom section. Maximum tip height: 81,4 m.
*
11,0 m - 18,0 m bifold swingaway extension. Hydraulically offsetable from 0° to
40°. Stows alongside base boom section. Maximum tip height: 81,4 m.
*
11,0 m - 18,0 m bifold swingaway extension with integrated 3,6 m 3-sheave heavy
duty jib. Hydraulically offsetable 0°,20° and 40°. Stows alongside base boom section.
Maximum tip height: 81,4 m.
*
1 x 8 m and 1 x 6 m lattice extension inserts. Installs between the boom nose and
bifold extension. Maximum tip height: 95,3 m.
One double acting hydraulic cylinder with integral holding valve provides elevation
from -3° to +78°.
Standard “Graphic Display” load moment and anti-two block system with audio-
visual warning and control lever lockout. ese systems provide electronic display of
boom angle, length, radius, tip height, relative load moment, maximum permissible
load, load indication and warning of impending two-block condition. e standard
Work Area Definition System allows the operator to pre-select and define safe
working areas. If the crane approaches the pre-set limits, audio-visual warnings aid
the operator in avoiding job-site obstructions.
Full-vision, all-steel fabricated with acoustical lining and tinted safety glass
throughout. Cab tilts to +20 degrees. Deluxe seat incorporates armrest-mounted
electric dual-axis controllers. Dash panel incorporates gauges for all engine func-
tions. Other standard features include: hot water heater, cab circulating air fan, air
conditioning, sliding side and rear windows, sliding skylight with electric wiper and
sunscreen, electric windshield wash/wipe, fire extinguisher and seat belt.
Two planetary swing drive with axial piston motors provide infinitely variable rota-
tion speeds. Foot applied multi-disc wet brake with Spring applied, hydraulically
released stationary swing brake. Two position mechanical house lock, operated from
cab. Maximum speed: 1,5 RPM.
17 690 kg. Hydraulically installed and removed.
* Additional 10886 kg (Total 28577 kg) hydraulically installed and removed.
Four main pumps with a combined capacity of 545 LPM.
Maximum operating pressure: 275,7 bar.
Three primary directional control valves with independent function sections.
Return line type filter with full flow by-pass protection and service indicator.
Replaceable cartridge with micron filtration rating of 10/12/5.
655 l hydraulic reservoir. System pressure test ports.
Planetary reduction with automatic spring applied multi-disc wet brake. Electronic
hoist drum rotation indicators, and hoist drum cable followers. 5th wrap indicator
with function cut-out.
Maximum Single Line Pull:
• 1st layer: 10 707 kg. • 3rd layer: 9 280 kg. • 5th layer: 7 852 kg.
Maximum Permissible Line Pull: 7 167 kg with 35x7 class rope.
Maximum Single Line Speed: 135 m/min.
Rope Construction: 35x7 WSC, Rotation Resistant. Rope Diameter: 19mm.
Rope Length: Main Hoist: 255 m - Auxiliary Hoist: 225 m.
Maximum Rope Stowage: Main hoist: 300 m - Auxiliary Hoist: 300 m.
Crane asset management system.
Carrier
Box section frame fabricated from high-strength, low alloy steel.
Removable outrigger boxes, front/rear towing and tie down lugs.
Four hydraulic telescoping single-stage double box beam outriggers with inverted
jacks and integral holding valves. ree position setting, 0%, 50% and fully
extended. Outrigger boxes removable for ease of transportation. All steel fabricated,
quick release type outrigger floats, 775 mm diameter. Maximum outrigger pad load:
75 300 kg. Controls and crane level indicator located in cab.
Engine
Engine (Tier III): Cummins QSC 8.3L diesel, six cylinders, 224 kW at 2200 rpm.
Maximum torque: 1356 Nm at 1400 rpm.
Note: Required for sale outside of North America and European Union countries.
Engine (Tier IV): Cummins QSL 8.3L diesel, six-cylinder, turbo charged with
Cummins diesel particulate exhaust filter/muffler. Meets U.S. E.P.A. Tier IV and
E.U. Stage IIIB. 239 kW at 2200 rpm. Maximum torque: 1383 Nm at 1500 rpm.
Fuel requirements: Maximum of 15 PPM sulphur content (Ultra Low Diesel Fuel)
Note: Tier IV engine required in North America and European Union countries.
Fuel tank capacity: 379 l.
Range-shift 6 x 3 speed (3 speeds x 2 range) 6 forward and 3 reverse.
Front axle disconnect for 4 x 2 travel.
4 x 4. Fully independent power steering:
Front: Full hydraulic steering wheel controlled.
Rear: Full hydraulic switch controlled.
Provides infinite variations of 4 main steering modes: front only, rear only, crab and
coordinated. Rear steer indicator. Turning radius: 9,7 m.
Front: Drive/steer with differential and planetary reduction hubs rigid mounted to
frame.
Rear: Drive/steer with differential and planetary reduction hubs pivot mounted to
frame.
Std. 33,25 X 29 - 38 bias ply.
Dry disc, full hydraulic split circuit operating on all wheels. Spring-applied, hydrau-
lically released parking brake mounted on front axle.
Full lighting including turn indicators, head, tail, brake and hazard warning lights.
24 km/h.
70% (at engine stall) Based on 87 751 kg GVW, 33.25 x 29 tires, 60,0 m main boom,
11,0-18,0 m manual bi-fold swingaway, 17 690 kg counterweight, 90 t hookblock and
9,0 t headache ball.
Four 12 V - maintenance free batteries. 24 V starting and lighting, circuit breakers.
CanBus Diagnostic system.
*
• Auxiliary lighting package (includes cab mounted amber ashing light, hoist
mounted work light, single base boom mounted floodlights and rubber mat for
stowage trough).
• Heavy Lift counterweight package
• ECOS event recorder
• Hardwired wind speed indicator
• Rear Pintle Hook
• Boom mounted aircraft warning light
• -28°C (-20°F) cold weather package
• Hydraulic bi-fold swingaway
• Hydraulic bi-fold swingaway with heavy duty jib
• Boom extension inserts
• CE mark conformance
*Denotes optional equipment
