MAINTENANCE CHECKLIST NBT30H-2 OPERATOR MANUAL
6-6
Published 03-18-2019 Control # 582-04
.
CRANE ADJUSTMENTS AND REPAIRS
Before adjustments and repairs are started on a crane, read
and be familiar with the safety information outlined under
Maintenance, page 2-26.
Boom Extension Cable
If a cable replacement is required for the boom extension
system, the replacement cable must be obtained through
Manitowoc Crane Care. Extension cables are pre-stretched
and have special connections for proper installation
Extension Jack Service and Maintenance
Important: Use only a good grade hydraulic jack oil,
transmission oil, or turbine oil. Avoid mixing types of oil. Do
not use brake fluid, alcohol, glycerin, detergent motor oil, or
dirty oil. Improper fluid can cause serious internal damage to
the jack rendering it inoperative.
Adding Oil to the Extension Jack
To add oil to the extension jack, do the following:
1. Set the jack in an upright level position.
2. Lower the saddle and make sure the piston is fully
depressed.
3. Remove the oil filler plug.
4. Fill until the oil is level with the filler plug hole.
Changing the Extension Jack Oil
For best performance and longest life, replace the oil at least
once a year. To change oil, do the following:
1. Remove the filler plug.
2. Lay the jack on its side and drain the oil into a suitable
drain pan. The oil will run slowly because air must enter
as the oil drains out.
3. Be careful to prevent dirt or foreign matter from entering
the system.
4. Replace with proper oil as described above.
Lubrication
Add proper lubrication oil to all pivoting sections every three
months.
Rust Prevention
Check the ram every three months for any sign of rust or
corrosion. Clean as needed and wipe with an oil saturated
cloth.
NOTE: When not in use, always leave the saddle and ram
all the way down.
HYDRAULIC SYSTEM
Oil Cooler
The heat exchanger must be kept clean for efficient
operation of the hydraulic cooler system. Wash the heat
exchanger core frequently to eliminate oil film, road dirt, and
other foreign object buildup on the heat exchanger fins.
Frequent inspection and tightening of hose clamps
eliminates the possibility of end connection failure due to
back pressure from a cold startup.
If the cooler system fails to provide adequate performance,
reduced air or oil flow through the heat exchanger is the
probable cause. Inspect the cooling fan for proper operation.
Any obstructions to air flow should be corrected (cooler too
close to other truck components, foreign matter in heat
exchanger fins, etc.) All hydraulic lines should be periodically
checked for obstructions, hose kinks or other flow
restrictions.
TIRE LOAD AND INFLATION TABLE
Definite tire inflation pressures are established for each tire
size depending upon the load imposed on the tires. For
greater stability, riding comfort and prolonged tire life, tires
should be inflated for the loads carried. The load and inflation
table shown below indicates the proper inflation pressure.
NOTE: The values in the tables below are as published by
the Tire and Rim Association, 2005. Your vehicle
may be equipped with other tire sizes or the same
size tires rated differently. Always check the tire
sidewalls to verify the maximum capacity and
inflation. Inflation pressure and loading must not
exceed the values shown on the wheel or rim.
Standard
14.3mm (9/16 in.) Dia. Wire cable:
Rotation Resistant
18X25 Nominal Breaking Strength:
17,463 kg (19.25 Tons)
Optional
14.3mm (9/16 in.) Dia. Wire cable:
6X25 General Purpose
6X25 Nominal Breaking Strength:
15,241 kg (16.8 tons)
