Proceeding : TOP COVER → TRAY PANEL → FRONT PANEL ASSY → MECHA ASSY
(1) Remove the screws.
3. MECHA ASSY
(2) Short the pickup protective solder for the CD mechanism. Then remove the connector and FFC.
Be sure to wear an earth band.
Remove the connector.
Soldering place
FFCCWC100 CWC101
26
