TROUBLE SHOOTING
1. POWER
1.1. The unit does not power on
Does the ON/STANDBY indicator on the front panel light turn red when the power is turned on?
NO
NO
NO
NO
NO
YES
Is the POWER PCB connector disconnected?
• [CN3901, CN3902, CN3903]
Connect the connectors correctly.
Connect the connectors correctly.
Connect the connectors correctly.
Replace the STANDBY TRANS [T3901].
[U3904] Check the input voltage and solder on
any other circuits that carry this output.
Replace [U3904] if there are no abnormalities.
Is the power relay drive con-
trol signal (STBY_CNT) being
received?
• [BN2801 11pin] ON signal
(+3.3V)
or
• [D3934] anode Low signal
(0V)
Check the signal line [IC302 19 pin] from UCOM of the MAIN PCB
and the solder of surrounding circuits.
Replace UCOM if any abnormalities are found.
• [IC302]
Replace the relay [S3901] if
the power relay drive control
signal (STBY_CNT) is normal.
Is the MAIN PCB connector disconnected?
• [BN2801]
Is the STANDBY PCB connector disconnected?
• [BN4101]
Is the STANDBY TRANS winding wire on the
POWER PCB broken?
• [T3901]
Is the ST+3.3V output voltage of the POWER PCB
normal?
• [BN2801 5pin] (ST+3.3V)
Has the POWER PCB power
relay switched?
• [S3901]
Has the TRANS PCB fuse
blown?
• [F3903, F3951, F3952]
Is the Main Trans [T3951] pri-
mary side winding wire on the
TRANS PCB broken?
Check the rectier diode and
also for short circuits in the
secondary side rectier circuit.
Has the regulator output
terminal of the power supply
stabilizer on the secondary
side or the connection be-
tween the circuit and GND
short circuited?
Replace the fuse. Also, replace
the main trans [T3951] if there
is an open circuit between
[BN3920 1-2 pins] or [T3951
12-2 pins].
Replace the fuse. Afterwards,
check the rectier diodes and
also for short circuits on each
of the secondary side recti-
er circuits; replace any faulty
parts.
Replace the fuse. Afterwards,
check the rectier diodes and
also for short circuits on each
of the secondary side recti-
er circuits; replace any faulty
parts.
YES
YES
YES
YES
NO
NO YES
NO
YES YES
YES
YES
NO
NO
NO
YES
YES
YES
