FR PW AD
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
B4301 nsp WIRE ASS'Y CWE8202150RV 1
BK10 nsp BRACKET , PCB U CMD1A569-V1 1
BK11 nsp BRACKET , PCB U CMD1A569-V1 1
BK12 nsp BRACKET , PCB CMD1A569-V1 1
BK13 nsp BRACKET , PCB CMD1A569-V1 1
BK41 nsp EARTH PLATE (HP) VMC1A491 1 *
BN1101 nsp USB WIRE ASS'Y (5PIN,350MM,61205032500AS) CWZCD6004B1101 1
BN2101 nsp WAFER, FFC(19P-1.25mm, STRAIGHT) CJP19GA115ZY 1
BN2201 nsp WIRE ASS'Y (3PIN,140MM,61205032800AS) U CWZCD6004B2201 1
BN2801 nsp WIRE ASS'Y (13PIN,80MM,61205032400AS) CWZCD6004B2801 1
BN3301 nsp WIRE ASS'Y(9P, SHIELD, 120mm, 2.0mm) CWB1C0091207E001 1 *
BN3504 nsp WIRE ASS'Y (5PIN,300MM,61205032600AS) CWZCD6004B3504 1
BN3902 nsp WIRE ASS'Y(2P, 220mm,3.96mm) CWB4D932200UZ 1 *
BN3903 nsp WIRE ASS'Y (10PIN,120MM,61205032300AS) CWZCD6004B3903 1
BN4101 nsp WIRE ASS'Y (5PIN,40MM,61205032700AS) CWZCD6004B4101 1
CN3301 nsp WAFER, STRAIGHT, 9PIN CJP09GA19ZY 1
CN3504 nsp LOCKING TYPE , STRAIGHT WAFER , 2.5MM CJP05GI237ZW 1
CN3901 nsp WAFER, 2P, 3.96mm CJP02KA060ZY 1
CN3902 nsp WAFER, 2P, 7.92mm CJP02GA89ZY 1
CN3903 nsp LOCKING TYPE , STRAIGHT WAFER , 2.5MM 10PIN CJP10GI237ZW 1
CN4101 nsp WAFER , STRAIGHT CJP05GA19ZY 1
F3001 nsp HOLDER , FUSE KJCFC5S 2
! F3001 90M-FS001370R FUSE
(
218Series, 250V/630mA
)
U, F KBA2C0630TLE
Y
12
! F3001 90M-FS001260R FUSE
(
218Series, 250V/315mA
)
N, K KBA2C0315TLE
Y
1
! F3903 943652500330M FUSE
(
372 Series/4A/TR5
)
CBA2D4000A3EY
T
1
! F3951 90M-FS001530
R
FUSE
(
0.8A, 372 SERIES/TR5
)
KBA2D0800A3EY
T
1
! F3952 90M-FS001530
R
FUSE
(
0.8A, 372 SERIES/TR5
)
KBA2D0800A3EY
T
1
FCB300 nsp WAFER, FFC(19P-1mm, STRAIGHT) CJP19GA117ZY 1
K3101 943643002370S JACK , 1P BOARD (WHITE, GD PLATE) CJJ4M064Z 1
K3201 943643002380S JACK , 1P BOARD (RED, GD PLATE) CJJ4M065Z 1
K3601 90M-YT004860R JACK, STEREO (BLK MOLD) U CJJ2D008Z 1
K4003 943643100150S JACK , USB STRAIGHT(BLACK) CJJ9X006Z 1
K4301 943643102640M JACK , PHONE(6.3mm,4PIN,Silver) CJJ2E036Z 1
L3301 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 1
L3302 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 1
L3303 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 1
L3304 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 1
L3305 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 1
L3306 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 1
L3307 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 1
L3405 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 1
L4001 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 1
L4002 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 1
L4003 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 1
L4004 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 1
L4301 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 1
L4302 nsp FERRITE , CHIP BEAD(60ohm, 2012) CLZ9R001Z 1
L4303 nsp FERRITE , CHIP BEAD(60ohm, 2012) CLZ9R001Z 1
L4304 nsp FERRITE , CHIP BEAD(60ohm, 2012) CLZ9R001Z 1
L4305 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 1
L4306 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 1
L4307 nsp FERRITE , CHIP BEAD(60ohm, 2012) CLZ9R001Z 1
L4308 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 1
L4401 nsp FERRITE CHIP BEAD(2012/220R) CLZBLM21PG221SN1 1
! S3901 943682100540S RELAY ,DC6V , 1C1P, 0.25
W
CSL1E007ZE 1
S4001 00D9430004402 SW , TACT CST1A012ZT 1
S4002 00D9430004402 SW , TACT CST1A012ZT 1
S4003 00D9430004402 SW , TACT CST1A012ZT 1
S4004 00D9430004402 SW , TACT CST1A012ZT 1
S4005 00D9430004402 SW , TACT CST1A012ZT 1
S4006 00D9430004402 SW , TACT CST1A012ZT 1
S4007 00D9430004402 SW , TACT CST1A012ZT 1
S4101 00D9430004402 SW , TACT CST1A012ZT 1
! T3901 943101002880M TRANS , SUB C51
5
U CLT5I009ZU 1
! T3901 90M-TS003180
R
TRANS , SUB CD6002/N N, K CLT5I009ZE 1
! T3901 90M-TS003170
R
TRANS , SUB CD6002/
F
F CLT5I009ZJ 1
U3601 262010007707S REMOTE SENSOR , R94EV1A U CRVR94EV1A 1
V4301 943129500940M V092Q20FA103 (METAL)(00D2115646001) CVV2U02A103Z 1
Z3501 nsp WIRE ASS'Y(1P, 80MM,BLK,#22) CWE5202080A 1
Z3503 nsp WIRE ASS'Y(1P, 80MM,BLK,#22) CWE5202080A 1
Z3504 nsp WIRE ASS'Y(1P, 80MM,BLK,#22) CWE5202080A 1
Z3911 nsp WIRE ASS'Y(1P, 80MM,BLK,#22) CWE5202080A 1
Z4001 nsp WIRE ASS'Y(1P, 80MM,BLK,#22) CWE5202080A 1
@ nsp FL SUPPORT CHG1A584 2
@ nsp SHIELD , CASE FLASHER U CMC1A441 1
