Pin
N0.
New Pin/Pad Name Connect Device Direction Detail
23 TDI .TDI PLD UPDATE IN Test Data Input for JTAG
24 TCK .TCK PLD UPDATE IN Test Clock for JTAG
25 TDO .TDO PLD UPDATE OUT Test Data Out for JTAG
26 IO .SLAVE_MCK CD MECHA OUT CD MECHA MCK(33.8688MHz)
27 IO .DAC_DSD_DATAL DSD1792A OUT DAC_DSD_DATAL
28 IO .DAC_DSD_DATAR DSD1792A OUT DAC_DSD_DATAR
29 IO .DAC_DSD_BCK DSD1792A OUT DAC_DSD_BCK
30 IO .DAC_LRCK DSD1792A OUT DAC_LRCK
31 VCCIO1 33_VCCIO DA3.3V - Power Supply
32 GNDIO GND DGND - Ground
33 IO .DAC_DATA DSD1792A OUT DAC_DATA
34 IO .DAC_BCK DSD1792A OUT DAC_BCK
35 IO
.DAC_
MCK_22.5792M
DAC_MCK 22M IN DAC_MCK 22.5792MHz
36 IO .22.5792M_DIR DIR_MCK 22M IN DIR_MCK 22.5792MHz
37 IO .22.5792M_USBA USBA_MCK 22M IN USBA_MCK 22.5792MHz
38 IO .DAC_MCK_24.576M DAC_MCK 24M IN DAC_MCK 24.576MHz
39 IO PLD_AMUTE AUDIO MUTE OUT ANALOG Mute
40 IO .44/48 AUDIO UNIT SELECTOR OUT Switch MCK (22M/24M)
41 IO .DAC_CS_OUT DSD1792A OUT DAC_CS_OUT
42 IO .DAC_DATA_OUT DSD1792A OUT DAC_DATA_OUT
43 IO/DEV_OE .DAC_CK_OUT DSD1792A OUT DAC_CK_OUT
44 IO/DEV_CLRn 3.3DD_MONI +3.3DD IN +3.3DD Moni
45 VCCIO1 33_VCCIO DA3.3V - Power Supply
46 GNDIO GND DGND - Ground
47 IO .DAC_RST_OUT DSD1792A OUT DAC RST
48 IO .CS2000MCK_OUT CS2000 OUT CS2000MCK_OUT
49 IO .CS2000MCK_IN CS2000 IN CS2000MCK_IN
50 IO .PLD_RSV3 M3062LFGPGP OUT PLD_RSV3
51 IO .PLD_DAC_SEL AUDIO UNIT SELECTOR OUT PLD_DAC_SEL
52 IO .DAC_CK_IN M3062LFGPGP IN DAC_CK_IN : for L/Rch DAC :to DSD1792A MC
53 IO .DAC_CS_IN M3062LFGPGP IN DAC_CS_IN : for L/Rch DAC:to DSD1792A MS
54 IO .DAC_DATA_IN M3062LFGPGP IN DAC_DATA_IN : for L/Rch DAC:to DSD1792A MDI
55 IO .USBB_MODE M3062LFGPGP IN USB_B_MODE
56 IO .DIR1_MCK PCM9211 IN DIR_MCK
57 IO .DIR1_BCK PCM9211 IN DIR_BCK
58 IO .DIR1_LRCK PCM9211 IN DIR_LRCK
59 VCCIO2 33_VCCIO DA3.3V - Power Supply
60 GNDIO GND DGND - Ground
61 IO .DIR1_DATA PCM9211 IN DIR_DATA
62 IO/GCLK2 .ERROR PCM9211 IN DIR_ERROR
63 VCCINT 33_VCCIO DA3.3V - Power Supply
64 IO/GCLK3 .USBB_DSD_PCM
"TMS320C6748BZWT3
/M3062LFGPGP"
IN USBB_DSD_PCM
65 GNDINT GND DGND - Ground
66 IO .USBB_44/48
"TMS320C6748BZWT3
/(M3062LFGPGP)"
IN USBB Moni (44.1kHz:L/48kHz:H)
67 IO .USBB_DSD_BCK TMS320C6748BZWT3 IN USBB_DSD_BCK
68 IO
.USBB_DSD_DATA_
L
TMS320C6748BZWT3 IN USBB_DSD_DATA_L
69 IO
.USBB_DSD_DATA_
R
TMS320C6748BZWT3 IN USBB_DSD_DATA_R
70 IO .CD_USBB_DIR M3062LFGPGP IN MODE (CD,USBB/DIR) Detect
71 IO NC CS2000 - NC
72 IO USBB_MUTE TMS320C6748BZWT3 IN USBB Mute Control
73 IO NC - - NC
74 IO NC - - NC
75 IO NC - - NC
76 IO ./INT_EXT M3062LFGPGP IN INT/EXT selection port
77 IO .D_MUTE M3062LFGPGP IN Moni USBB_PCM→DSD MUTE timing
78 IO .DAC_CONT_SEL M3062LFGPGP IN DAC_CONT_SEL (SYSCON/DV3.2)
79 GNDIO GND DGND - Ground
80 VCCIO2 33_VCCIO DA3.3V - Power Supply
81 IO .DAC_RST_IN M3062LFGPGP IN DAC_RST_IN : for L/Rch DAC:to DSD1792A RST
82 IO .DSD_MUTE_F M3062LFGPGP IN
EN_VER(DSD_MUTE_F) : USBB_DSD→PCM MUTE
timing
69
