FRONT
FRONT PCB ASS'
Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed
b
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver gold model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D1251-1262 20105001230AS 1SS355T 20105001230AS 1
D2501-2508 26301000440AS SELG6E10C-S20 BLUE LED 26301000440AS 1
D2509,2510 176010009406S SELK2E14C-D BLUE LED 176010009406S 1
D2511 263010041403S SLI-343V8RC(T32) 263010041403S 1
D2512 176010009406S SELK2E14C-D BLUE LED 176010009406S 1
D4501-4508 00MHZ2001805Y 1SS302 (TE85L F) (TOSHIBA) 00MHZ2001805Y 1
D7501,7502 20105001130AS 1SS133(HOMI) 20105001130AS 1
! D8501-8504 00MHD20055101 !SHOTTKY 11EQS10 1A 100
V
00MHD20055101 1
D8505,8506 20305002730AS 1N4003(HOMI) 20305002730AS 1
D8507 00D2760683985 UDZS11B-TE17 00D2760683985 1
D8508 20105001130AS 1SS133(HOMI) 20105001130AS 1
! D8509-8512 00MHD20055101 !SHOTTKY 11EQS10 1A 100
V
00MHD20055101 1
D8513-8518 20305002730AS 1N4003(HOMI) 20305002730AS 1
D8530 00D2760683901 UDZS5.6B-TE17 +C 00D2760683901 1
Q1251,1252 00D2690184907 KRA102S-RTK/P (10K-10K) 00D2690184907 1
Q1801 00MHT600141B1 KTA1271 PNP TRANSISTOR RANK=Y 00MHT600141B1 1
Q1802 00MHT800951B1 KTC3203 NPN TRANSISTOR RANK=Y 00MHT800951B1 1
Q1803 00MHT600141B1 KTA1271 PNP TRANSISTOR RANK=Y 00MHT600141B1 1
Q1804 00MHT800951B1 KTC3203 NPN TRANSISTOR RANK=Y 00MHT800951B1 1
Q1805,1806 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q2501-2512 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q2551-2555 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q2601 00D2690184907 KRA102S-RTK/P (10K-10K) 00D2690184907 1
Q2602 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q2801 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q4501,4502 22255001850AS 2SK2145GR/BL(5LDMH.F) 22255001850AS 1
Q4503,4504 21305002050AS 2SC6126 21305002050AS 1
Q4505,4506 21105002140AS KSA992FTA 21105002140AS 1
Q4507,4508 21305002440AS KSC1845FTA 21305002440AS 1
Q4509,4510 21105002140AS KSA992FTA 21105002140AS 1
Q4511,4512 21305002440AS KSC1845FTA 21305002440AS 1
Q4513,4514 21105002140AS KSA992FTA 21105002140AS 1
Q4515,4516 21305002440AS KSC1845FTA 21305002440AS 1
Q4517,4518 21105002140AS KSA992FTA 21105002140AS 1
Q4519-4522 21305002440AS KSC1845FTA 21305002440AS 1
Q4523,4524 21105002140AS KSA992FTA 21105002140AS 1
Q4525-4528 00D2730460905 KTC2875-B-RTK/P 00D2730460905 1
Q4529 00D2690184907 KRA102S-RTK/P (10K-10K) 00D2690184907 1
Q4530,4531 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q4801 00D2757001907 FDC608PZ 00D2757001907 1
Q8501 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q8502 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 1
! Q8530 00MHT348832A
0
TRANSISTOR 2SC4883 O OR
Y
00MHT348832A
0
1
U2001,2002 23281004150AS NJM8080G 23281004150AS 1
U2004 23281004150AS NJM8080G 23281004150AS 1
U2551,2552 234810014504S MC14094BDTR2G 234810014504S 1
U2601 262010010000S R34ES9A-15MM(36KHZ) IR RECIVER 262010010000S 1
U4001 00D2630896909 NJM2068MD-TE1 +C 00D2630896909 1
! U4801 00D2630809006 NJM7805FA
(
S
)
00D2630809006 1
! U4802 231310009508S PQ033DNA1ZPH 231310009508S 1
! U8501 00D2631240907 BA33B00FP-E2 00D2631240907 1
RESISTOR GROUP
R1013 nsp RM73B--104JT +1608 00D2472012925 1
R1251,1252 nsp RM73B--124JT +1608 00D2472012941 1
R1253-1255 nsp RM73B--103JT +1608 00D2472009983 1
R1256 nsp RM73B--472JT (1608) +1608 00D2472009909 1
R1257 nsp RM73B--152JT +1608 00D2472007985 1
R1258 nsp RM73B--392JT +1608 00D2472008984 1
R1259,1260 nsp RM73B--152JT +1608 00D2472007985 1
R1261 nsp RM73B--222JT +1608 00D2472008926 1
R1262 nsp RM73B--152JT +1608 00D2472007985 1
R1263 nsp RM73B--101JT +1608 00D2472005903 1
R1264 nsp RM73B--122JT +1608 00D2472007969 1
R1265 nsp RM73B--101JT +1608 00D2472005903 1
R1266,1267 nsp RM73B--222JT +1608 00D2472008926 1
R1268,1269 nsp RM73B--182JT +1608 00D2472008900 1
R1270 nsp RM73B--223JT +1608 00D2472010969 1
R1271 nsp RM73B--103JT +1608 00D2472009983 1
R1801,1802 nsp RM73B--222JT +1608 00D2472008926 1
R1803,1804 nsp RM73B--473JT +1608 00D2472011942 1
R1805 nsp RM73B--222JT +1608 00D2472008926 1
R1806 nsp RM73B--473JT +1608 00D2472011942 1
R1808 nsp RM73B--222JT +1608 00D2472008926 1
R1809 nsp RM73B--473JT +1608 00D2472011942 1
R2001,2002 nsp RD14B2E333JT(5) 00D2412402919 1
! R2003,2004 00MGG0510016
X
10 OHM +- 5% 1/6W 00MGG0510016
X
1
R2005,2006 nsp RD14B2E333JT(5) 00D2412402919 1
R2007-2010 nsp RD14B2E272JT(5) 00D2412399954 1
R2011,2012 nsp RD14B2E104JT(5) 00D2412403934 1
R2013,2014 nsp RD14B2E101JT(5) 00D2412396928 1
R2015,2016 nsp RD14B2E122JT(5) 00D2412398971 1
R2017,2018 nsp RD14B2E473JT(5) 00D2412402951 1
R2023,2024 nsp RD14B2E122JT(5) 00D2412398971 1
R2025,2026 nsp RD14B2E563JT(5) 00D2412402977 1
R2501 nsp RM73B--103JT +1608 00D2472009983 1
R2502 nsp RM73B--331JT (1608) +1608 00D2472006902 1
R2503 nsp RM73B--103JT +1608 00D2472009983 1
R2504 nsp RM73B--331JT (1608) +1608 00D2472006902 1
R2505 nsp RM73B--103JT +1608 00D2472009983 1
R2506 nsp RM73B--331JT (1608) +1608 00D2472006902 1
R2507 nsp RM73B--103JT +1608 00D2472009983 1
R2508 nsp RM73B--331JT (1608) +1608 00D2472006902 1
R2509 nsp RM73B--103JT +1608 00D2472009983 1
R2510 nsp RM73B--331JT (1608) +1608 00D2472006902 1
R2511 nsp RM73B--103JT +1608 00D2472009983 1
R2512 nsp RM73B--331JT (1608) +1608 00D2472006902 1
R2513 nsp RM73B--103JT +1608 00D2472009983 1
R2514 nsp RM73B--331JT (1608) +1608 00D2472006902 1
