FRONT
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
R2515 nsp RM73B--103JT +1608 00D2472009983 1
R2516 nsp RM73B--331JT (1608) +1608 00D2472006902 1
R2517 nsp RM73B--103JT +1608 00D2472009983 1
R2518 nsp RM73B--221JT +1608 00D2472005987 1
R2519 nsp RM73B--103JT +1608 00D2472009983 1
R2520 nsp RM73B--221JT +1608 00D2472005987 1
R2522 nsp RM73B--122JT +1608 00D2472007969 1
R2523 nsp RM73B--103JT +1608 00D2472009983 1
R2524 nsp RM73B--221JT +1608 00D2472005987 1
R2553-2557 nsp RM73B--101JT +1608 00D2472005903 1
R2558-2562 nsp RM73B--103JT +1608 00D2472009983 1
R2602 nsp RD14B2E101JT(5) 00D2412396928 1
R2701 nsp RM73B--103JT +1608 00D2472009983 1
R2702 nsp RM73B--222JT +1608 00D2472008926 1
R2703-2705 nsp RM73B--392JT +1608 00D2472008984 1
R2706 nsp RM73B--223JT +1608 00D2472010969 1
R4001,4002 nsp RD14B2E682JT(5) N,K 00D2412400953 2
R4003-4006 nsp RD14B2E104JT(5) 00D2412403934 1
R4007,4008 nsp RD14B2E330JT(5) U,F 00D2412395903 2
R4007,4008 nsp RD14B2E101JT(5) N,K 00D2412396928 2
R4009,4010 nsp RD14B2E820JT(5) 00D2412396902 1
R4011,4012 nsp RD14B2E823JT(5) 00D2412403918 1
R4013,4014 nsp RD14B2E682JT(5) 00D2412400953 1
R4015,4016 nsp RD14B2E101JT(5) 00D2412396928 1
R4017,4018 nsp RD14B2E473JT(5) 00D2412402951 1
R4019,4020 nsp RD14B2E101JT(5) 00D2412396928 1
! R4021,4022 00MGG0510016
X
10 OHM +- 5% 1/6W 00MGG0510016
X
1
R4501-4504 nsp RD14B2E102JT(5) 00D2412398955 1
R4505-4512 nsp RD14B2E183JT(5) 00D2412401952 1
R4513,4514 nsp RD14B2E103JT(5) 00D2412400995 1
R4515,4516 nsp RD14B2E472JT(5) 00D2412400911 1
R4517,4518 nsp RD14B2E103JT(5) 00D2412400995 1
R4519,4520 nsp RD14B2E472JT(5) 00D2412400911 1
R4521-4524 nsp RD14B2E121JT(5) 00D2412396944 1
R4525,4526 nsp RD14B2E680JT(5) 00D2412395987 1
R4527,4528 nsp RD14B2E561JT(5) 00D2412397998 1
R4529,4530 nsp RD14B2E333JT(5) 00D2412402919 1
R4531,4532 nsp RD14B2E561JT(5) 00D2412397998 1
R4533,4534 nsp RD14B2E101JT(5) 00D2412396928 1
R4535,4536 nsp RD14B2E333JT(5) 00D2412402919 1
R4537-4540 nsp RD14B2E220JT(5) 00D2412394962 1
R4541-4544 nsp RD14B2E471JT(5) 00D2412397972 1
R4545-4548 nsp RD14B2E220JT(5) 00D2412394962 1
R4549,4550 nsp RD14B2E104JT(5) 00D2412403934 1
R4551-4554 nsp RD14B2E101JT(5) 00D2412396928 1
R4555,4556 nsp RD14B2E100JT(5) 00D2412393989 1
R4557-4560 nsp RM73B--102JT +1608 00D2472007943 1
! R4561-4564 00MGG0510016
X
10 OHM +- 5% 1/6W 00MGG0510016
X
1
R4565-4570 nsp RD14B2E822JT(5) 00D2412400979 1
R4801 nsp RM73B--472JT (1608) +1608 00D2472009909 1
R4802 nsp RM73B--103JT +1608 00D2472009983 1
R4823 nsp RM73B--472JT (1608) +1608 00D2472009909 1
! R7501,7502 00MGG0510016
X
10 OHM +- 5% 1/6W 00MGG0510016
X
1
R7503,7504 00MNK05331020 330 OHM +- 5% 2W 00MNK05331020 1
! R8501 00MGG0522016
X
22 OHM +- 5% 1/6W 00MGG0522016
X
1
R8502 nsp RM73B--823JT +1608 00D2472012909 1
R8503,8504 nsp RM73B--472JT (1608) +1608 00D2472009909 1
! R8505 00MBF68400016 ! 0.68UF/4.7OHM 00MBF68400016 1
! R8506,8507 00MGG05010120 ERD50FJ1R0P or SPRX1CM12.5A J 1R0 00MGG05010120 1
R8508 nsp RM73B--104JT +1608 00D2472012925 1
R8509 nsp RM73B--470JT +1608 00D2472004920 1
R8510 nsp RM73B--223JT +1608 00D2472010969 1
R8511 nsp RM73B--822JT +1608 00D2472009967 1
R8512 nsp RM73B--333JT +1608 00D2472011900 1
R8513 nsp RM73B--563JT +1608 00D2472011968 1
R8530 nsp RM73B--822JT +1608 00D2472009967 1
! R8531 00MGG0510016
X
10 OHM +- 5% 1/6W 00MGG0510016
X
1
CAPACIITORS GROUP
C1251 nsp CK73B1H103KT (1608) +1608 00D2570501901 1
C1801,1802 00D2544573949 CE04W1H010MT(RA3) 00D2544573949 1
C1803 nsp CK73B1H103KT (1608) +1608 00D2570501901 1
C2001,2002 00MOA22605021 22 UF M 50V RA-2 00MOA22605021 1
C2003-2006 133050086503S CQ93M2A221JT(PEF) 133050086503S 1
C2007,2008 00MOA22605021 22 UF M 50V RA-2 00MOA22605021 1
C2009,2010 00MOA10702521 100 UF M 25V RA-2 00MOA10702521 1
C2011,2012 13305030640AS CQ93P2A103JT(DTN) 13305030640AS 1 Ver.3
C2013,2014 133050086503S CQ93M2A221JT(PEF) 133050086503S 1
C2019,2020 00MEJ22505011 2.2UF/ 50V 00MEJ22505011 1
C2021,2022 13305030646AS CQ93P2A683JT(DTN) 13305030646AS 1 Ver.3
C2029 nsp CK73B1H103KT (1608) +1608 00D2570501901 1
C2030 nsp CK73F1E104ZT +1608 00D2570512903 1
C2501-2511 nsp CK73B1H103KT (1608) +1608 00D2570501901 1
C2551 00MEJ10602511 10UF/ 25V 00MEJ10602511 1
C2552,2553 nsp CK73F1E104ZT +1608 00D2570512903 1
C2554,2555 nsp CK73B1H102KT +1608 00D2570509929 1
C2557 nsp CK73B1H102KT +1608 00D2570509929 1
C2559 00MEJ10602511 10UF/ 25V 00MEJ10602511 1
C2602 nsp CK73B1H103KT (1608) +1608 00D2570501901 1
C2603 00D2544302974 CE04W1A101MT(SRE) 00D2544302974 1
C2701 00MEJ10602511 10UF/ 25V 00MEJ10602511 1
C2702 nsp CK73B1H103KT (1608) +1608 00D2570501901 1
C4000 nsp CK73F1E104ZT +1608 00D2570512903 1
C4001,4002 00MOF55221591 220PF 200V +- 10% FAS N,K 00MOF55221591 2
C4003,4004 00MOF55221591 220PF 200V +- 10% FAS 00MOF55221591 1
C4005,4006 00MOA10605021 10 UF M 50V RA-2 00MOA10605021 1
C4007,4008 00D2544577974 CE04W1C471MT(RA3) 00D2544577974 1
C4009,4010 133050088516S CQ93M2A393JT(PEF) 133050088516S 1
C4011,4012 13305030543AS CQ93P2A102JT(DTN) 13305030543AS 1 Ver.3
C4013,4014 13305030640AS CQ93P2A103JT(DTN) 13305030640AS 1 Ver.3
C4015,4016 00MOA10605021 10 UF M 50V RA-2 00MOA10605021 1
C4019,4020 00MOA22702521 220 UF M 25V RA-2 00MOA22702521 1
C4501,4502 133050125408S CQ93E2A561JT(FNS) 133050125408S 1
C4503-4506 133050125415S CQ93E2A821JT(FNS) 133050125415S 1
C4507-4510 133050079420S CQ93G2D181J(FAS) 133050079420S 1
C4511,4512 00MOF55221591 220PF 200V +- 10% FAS 00MOF55221591 1
C4515,4516 00MOA10605021 10 UF M 50V RA-2 00MOA10605021 1
