Marantz PM-10 User Manual

.
MF / HF
LF
MF / HF
LF
Remove
shorting bar
Super Audio CD player, etc.
: Signal flow
Set to “BI-AMP”.
Set to “BI-AMP”.
Set PM-10
for L channel to
ID 1
To power outlet.
To power outlet.
Remove
shorting bar
L channel
speaker
Remove
shorting bar
Remove
shorting bar
R channel
speaker
Set PM-10
for R channel to
ID 2
ENGLISH
13

Marantz PM-10 Specifications

General

Type	Integrated Amplifier
Frequency Response	5 Hz - 50 kHz
Total Harmonic Distortion	0.005%
Dimensions	440 x 168 x 453 mm
Weight	21.5 kg
Damping Factor	500
Available Colors	Silver, Black
Power Output	200W per channel (8Ω)
Input Sensitivity	220 mV / 22 kohm
