Advanced connections
F.C.B.S. connection
Connection for 5.1 Multi-channel Playback
The three units are connected using F.C.B.S. For the F.C.B.S connection, prepare 3 audio connection cables, and refer to F.C.B.S. ( vpage14).
Connect the outputs of players that have 5.1 channel analog outputs to each of the three units.
If using an active subwoofer, see the instruction manual that came with the subwoofer for further instructions.
Set the ID numbers for the three amplifiers as explained in How to set ID number for F.C.B.S. (vpage15).
t8IFOUIF*%VOJUJTPQFSBUFE*%BOE*%VOJUTXJMMPQFSBUFJOTZOD
3
1 2
3
1 2
3
1 2
3
1 2
3
1 2
3
1 2
FRONT R FRONT L SURROUND R
MULTI CHANNEL AUDIO OUT
SURROUND L SUB-WOOFER CENTER
tSet SPEAKER A button on front panel in
ON position.
tSet to “STEREO”.
tSet SPEAKER A button on front panel in ON position.
tSet PRE OUT button on front panel in ON position.
tSet to “STEREO”.
For front L/R speakers
Set PM-11S3 to ID 1.
For center speaker or subwoofer
Set PM-11S3 to ID 2.
For surround speakers
Set PM-11S3 to ID 3.
To power
outlet.
To power
outlet.
tSet SPEAKER A button on front panel in
ON position.
tSet to “STEREO”.
To power
outlet.
L CH front
speaker
R CH front
speaker
Active
subwoofer
To line input
jack
Front center
speaker
L CH surround
speaker
R CH surround
speaker
SACD multi-channel player, etc.

Marantz PM-11S3 Specifications

General

Damping factor	100
Amplifier class	-
Frequency range	5 - 100000 Hz
Input sensitivity	240 mV
Audio output channels	2.0 channels
Peak power per channel	200 W
Signal-to-Noise Ratio (SNR)	96 dB
Total Harmonic Distortion (THD)	0.01 %
Dynamic power per channel (8 Ohm)	100 W
XLR in	Yes
Headphone outputs	1
Line inputs (RCA)	2
Headphone connectivity	6.3 mm
Speakers connectivity type	Clamp terminals
Material	Metal
Cooling type	Passive
Product color	Black, Gold
Volume control	Rotary
Connectivity technology	Wired
Power consumption (standby)	0.3 W
Power consumption (typical)	300 W

Weight and Dimensions

Depth	449 mm
Width	440 mm
Height	168 mm
Weight	27000 g
