Index
v A
Accessories ·························································· 1
Adjust the levels (Left and Right) ······················· 12
Adjust the tone ··················································· 12
Adjust the volume ·············································· 11
Auto standby mode ············································ 20
v B
Batteries ······························································· 2
v C
Cable
Balance cable ····················································· 6
Pin-plug cable····················································· 6
Speaker cable ···················································· 6
Condensation ······················································· 2
Connection
5.1 Multi-channel Playback ······························ 17
Bi-wiring ····························································· 8
Cables ································································ 6
Player ································································· 9
Power Amp Direct ··········································· 19
Power cord ······················································ 10
PRE OUT connectors ······································· 19
Recorder ·························································· 10
Remote control connectors ····························· 20
Speaker ······························································ 8
Stereo complete bi-amp ·································· 16
v F
F.C.B.S. connection ············································ 14
Front panel ··························································· 4
v H
High frequency range ········································· 12
v I
INPUT SELECTOR ·············································· 11
Inserting the batteries ·········································· 2
v L
Low frequency range ········································· 12
v M
MM/MC cartridge select ···································· 21
Muting the sound ··············································· 13
v P
Protection circuit ············································ 7, 21
v R
Remote control ···················································· 5
v S
Speaker impedance ········································ 7, 21
Specifications
t RMS Power output:
(20 Hz - 20 kHz 2-channel simultaneously driven)
100 W × 2 (8 )
200 W × 2 (4 )
t Total harmonic distortion:
(20 Hz - 20 kHz 2-channel simultaneously driven, 8 Ω)
0.01 %
t Output band width: (8 , 0.05 %) 5 Hz − 45 kHz
t Frequency response: (CD, 1 W, 8 load) 5 Hz − 120 kHz ± 3 dB
t Damping factor: (8 , 20 Hz − 20 kHz) 100
t Input sensitivity/Input impedance
PHONO (MC): 260 µV / 100
PHONO (MM): 2.7 mV / 47 k
BALANCED: 480 mV / 40 k
CD/LINE: 240 mV / 20 k
P. DIRECT IN: 1.7 V / 20 k
t Output voltage/Output impedance
PRE OUT: 1.9 V / 220
t Maximum allowable PHONO input level (1 kHz)
MC: 10 mV
MM: 105 mV
t RIAA deviation: (20 Hz−20 kHz) ± 0.5 dB
t S/N (IHF-A, 8 Ω)
PHONO (MC): 76 dB (0.5 mV Input, 1 W Output)
PHONO (MM): 88 dB (5 mV Input, 1 W Output)
BALANCED: 109 dB (4 V Input, Rated output)
CD/LINE: 108 dB (2 V Input, Rated output)
t Tone control
BASS (50 Hz): ± 8 dB
TREBLE (20 kHz): ± 8 dB
t Power requirement: AC 120 V, 60 Hz
t Power consumption (UL60065): 300 W
t Standby power consumption: 0.2 W
