Marantz PM-15S1 Service Manual

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PCB
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
P101 R521 ns
p
00MGD0510116
0
RES. 100 OHM +- 5% 1/6
W
P101 R522 ns
p
00MGD0510116
0
RES. 100 OHM +- 5% 1/6
W
P101 R523 ns
p
00MGD0510116
0
RES. 100 OHM +- 5% 1/6
W
P101 R524 ns
p
00MGD0510116
0
RES. 100 OHM +- 5% 1/6
W
P101 R525 ns
p
00MGD0510016
0
RES. 10 OHM +- 5% 1/6
W
P101 R526 ns
p
00MGD0510016
0
RES. 10 OHM +- 5% 1/6
W
P101 R529 ns
p
00MGD0522116
0
RES. 220 OHM +- 5% 1/6
W
P101 R530 ns
p
00MGD0522116
0
RES. 220 OHM +- 5% 1/6
W
P101 R531 ns
p
00MGD0547016
0
RES. 47 OHM +- 5% 1/6
W
P101 R532 ns
p
00MGD0547016
0
RES. 47 OHM +- 5% 1/6
W
P101 R535 ns
p
00MGD0547216
0
RES. 4.7K OHM +- 5% 1/6
W
P101 R536 ns
p
00MGD0547216
0
RES. 4.7K OHM +- 5% 1/6
W
P101 R537 ns
p
00MGD0547216
0
RES. 4.7K OHM +- 5% 1/6
W
P101 R538 ns
p
00MGD0547216
0
RES. 4.7K OHM +- 5% 1/6
W
P101 R551 ns
p
00MGD0547216
0
RES. 4.7K OHM +- 5% 1/6
W
P101 R552 ns
p
00MGD0547216
0
RES. 4.7K OHM +- 5% 1/6
W
P101 R553 ns
p
00MGD0568216
0
RES. 6.8K OHM +- 5% 1/6
W
P101 R554 ns
p
00MGD0568216
0
RES. 6.8K OHM +- 5% 1/6
W
P101 R555 ns
p
00MGD0510416
0
RES. 100K OHM +- 5% 1/6
W
P101 R556 ns
p
00MGD0510416
0
RES. 100K OHM +- 5% 1/6
W
P101 R557 ns
p
00MGD0533116
0
RES. 330 OHM +- 5% 1/6
W
P101 R558 ns
p
00MGD0533116
0
RES. 330 OHM +- 5% 1/6
W
P101 R559 ns
p
00MGD0510116
0
RES. 100 OHM +- 5% 1/6
W
P101 R560 ns
p
00MGD0510116
0
RES. 100 OHM +- 5% 1/6
W
P101 R851 ns
p
00MGD0510216
0
RES. 1K OHM +- 5% 1/6
W
P101 R852 ns
p
00MGD0510216
0
RES. 1K OHM +- 5% 1/6
W
P101 R853 ns
p
00MGD0515316
0
RES. 15K OHM +- 5% 1/6
W
P101 R854 ns
p
00MGD0515316
0
RES. 15K OHM +- 5% 1/6
W
P101 R855 ns
p
00MGD0568116
0
RES. 680 OHM +- 5% 1/6
W
P101 R856 ns
p
00MGD0568116
0
RES. 680 OHM +- 5% 1/6
W
TONE VOL
,(
00MWG10AJ307-
)
P251 C251 00MOA22505020 00MOA22505020 ELECT. CAP. 2.2 UF M 50V RA-2
P251 C252 00MOA22505020 00MOA22505020 ELECT. CAP. 2.2 UF M 50V RA-2
P251 C253 00MOF15683040 00MOF15683040 FILM CAP. 0.068UF +-5% 50V MTFV
P251 C254 00MOF15683040 00MOF15683040 FILM CAP. 0.068UF +-5% 50V MTFV
P251 C255 00MOF15103540 00MOF15103540 FILM CAP. APSV 103J,0.01UF
(
TP
)
100V PP
P251 C256 00MOF15103540 00MOF15103540 FILM CAP. APSV 103J,0.01UF
(
TP
)
100V PP
P251 C257 00MOF15101540 00MOF15101540 FILM CAP. 100PF J 100V APSV
P251 C258 00MOF15101540 00MOF15101540 FILM CAP. 100PF J 100V APSV
P251 C259 00MOA10702520 00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
P251 C260 00MOA10702520 00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
P251 C261 00MOA10702520 00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
P251 C262 00MOA10702520 00MOA10702520 ELECT. CAP. 100 UF M 25V RA-2
P251 Q251 00MHC1005309
0
00MHC1005309
0
IC IC NJM2068DD:MON
O
P251 Q252 00MHC1005309
0
00MHC1005309
0
IC IC NJM2068DD:MON
O
P251 R251 00MRM0103128
0
00MRM0103128
0
VAR. RES. 10K
(
B
)
X2 K09G0A0
C
P251 R252 00MRM0103128
0
00MRM0103128
0
VAR. RES. 10K
(
B
)
X2 K09G0A0
C
P251 R253 ns
p
00MNN0512261
0
CHIP RES. 1.2K OHM +- 5% 1/16
W
P251 R254 ns
p
00MNN0512261
0
CHIP RES. 1.2K OHM +- 5% 1/16
W
P251 R255 ns
p
00MNN0556361
0
CHIP RES. 56K OHM +- 5% 1/16
W
P251 R256 ns
p
00MNN0556361
0
CHIP RES. 56K OHM +- 5% 1/16
W
P251 R257 ns
p
00MNN0512261
0
CHIP RES. 1.2K OHM +- 5% 1/16
W
P251 R258 ns
p
00MNN0512261
0
CHIP RES. 1.2K OHM +- 5% 1/16
W
P251 R259 ns
p
00MNN0556361
0
CHIP RES. 56K OHM +- 5% 1/16
W
P251 R260 ns
p
00MNN0556361
0
CHIP RES. 56K OHM +- 5% 1/16
W
PREOUT/MAININ SW
(
00MWA10AJ102-
)
P351 C351
/
K1G ns
p
00MOF15101540 FILM CAP. 100PF J 100V APSV
P351 C351
/
L1G ns
p
00MOF15101540 FILM CAP. 100PF J 100V APSV
P351 C351
/
N1G 00MOF15101540 00MOF15101540 FILM CAP. 100PF J 100V APSV
P351 C351
/
N1S 00MOF15101540 00MOF15101540 FILM CAP. 100PF J 100V APSV
P351 C351
/
S1G ns
p
00MOF15101540 FILM CAP. 100PF J 100V APSV
P351 C352
/
K1G ns
p
00MOF15101540 FILM CAP. 100PF J 100V APSV
P351 C352
/
L1G ns
p
00MOF15101540 FILM CAP. 100PF J 100V APSV
P351 C352
/
N1G 00MOF15101540 00MOF15101540 FILM CAP. 100PF J 100V APSV
P351 C352
/
N1S 00MOF15101540 00MOF15101540 FILM CAP. 100PF J 100V APSV
P351 C352
/
S1G ns
p
00MOF15101540 FILM CAP. 100PF J 100V APSV
52
