Marantz PM-15S1 Service Manual

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
PCB
NAME
POS. NO.
VERS.
COLOR
PART NO.
(
FOR EUR
)
PART NO.
(
MJI
)
PART NAME DESCRIPTION
P351 J351 00MYT02021130 00MYT02021130 TERMINAL 2P CINCH JACK YKC21-3255
(
GOLD
)
P351 L351 00MLY2024048
0
00MLY2024048
0
RELAY MR82-24US
R
PHONO AMP
(
00MWA10AJ203-
)
P401 C401 00MOF55102580 00MOF55102580 FILM CAP. 1000PF 100V FNS
P401 C402 00MOF55102580 00MOF55102580 FILM CAP. 1000PF 100V FNS
P401 C403 00MOF55101590 00MOF55101590 FILM CAP. 100PF 200V +- 5% FAS
P401 C404 00MOF55101590 00MOF55101590 FILM CAP. 100PF 200V +- 5% FAS
P401 C405 00MOF55102580 00MOF55102580 FILM CAP. 1000PF 100V FNS
P401 C406 00MOF55102580 00MOF55102580 FILM CAP. 1000PF 100V FNS
P401 C407 00MOA107025R0 00MOA107025R0 ELECT. CAP. ROA-25V 101M -H4#PE - T2
(
100UF 25V
)
P401 C408 00MOA107025R0 00MOA107025R0 ELECT. CAP. ROA-25V 101M -H4#PE - T2
(
100UF 25V
)
P401 C409 00MOF55681580 00MOF55681580 FILM CAP. 680PF 100V +-5% FNS
P401 C410 00MOF55681580 00MOF55681580 FILM CAP. 680PF 100V +-5% FNS
P401 C413 00MOF55103580 00MOF55103580 FILM CAP. 0.01UF 100V +- 5% FNS
P401 C414 00MOF55103580 00MOF55103580 FILM CAP. 0.01UF 100V +- 5% FNS
P401 C417 00MOF55393580 00MOF55393580 FILM CAP. 0.039UF 100V +- 5% FAS
P401 C418 00MOF55393580 00MOF55393580 FILM CAP. 0.039UF 100V +- 5% FAS
P401 C419 00MOF55102580 00MOF55102580 FILM CAP. 1000PF 100V FNS
P401 C420 00MOF55102580 00MOF55102580 FILM CAP. 1000PF 100V FNS
P401 C421 00MOA106035Z0 00MOA106035Z0 ELECT. CAP. ROS-35V 100M - F3#PE - T2
(
10UF 35V
)
P401 C422 00MOA106035Z0 00MOA106035Z0 ELECT. CAP. ROS-35V 100M - F3#PE - T2
(
10UF 35V
)
P401 C423 00MOA477025R0 00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6#PE - S13
(
470UF 25V
)
P401 C424 00MOA477025R0 00MOA477025R0 ELECT. CAP. ROA-25V 471M -I6#PE - S13
(
470UF 25V
)
P401 C425 00MOA47602520 00MOA47602520 ELECT. CAP. 47 UF M 25V RA-2
P401 C429
/
K1G ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
P401 C429
/
L1G ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
P401 C429
/
N1G 00MOF15221540 00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
P401 C429
/
N1S 00MOF15221540 00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
P401 C429
/
S1G ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
P401 C430
/
K1G ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
P401 C430
/
L1G ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
P401 C430
/
N1G 00MOF15221540 00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
P401 C430
/
N1S 00MOF15221540 00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
P401 C430
/
S1G ns
p
00MOF15221540 FILM CAP. APSV 221J,220PF
(
TP
)
100V PP
P401 C431 00MOF55101590 00MOF55101590 FILM CAP. 100PF 200V +- 5% FAS
P401 C432 00MOF55101590 00MOF55101590 FILM CAP. 100PF 200V +- 5% FAS
P401 D401 00MHD2000200
0
00MHD2000200
0
DIODE 1SS176,MA165,1SS254 30V 0.1
A
P401 D402 00MHD2000200
0
00MHD2000200
0
DIODE 1SS176,MA165,1SS254 30V 0.1
A
P401 D403 00MHD2000200
0
00MHD2000200
0
DIODE 1SS176,MA165,1SS254 30V 0.1
A
P401 D404 00MHD2000200
0
00MHD2000200
0
DIODE 1SS176,MA165,1SS254 30V 0.1
A
P401 D405 00MHD2000200
0
00MHD2000200
0
DIODE 1SS176,MA165,1SS254 30V 0.1
A
P401 D406 00MHD2000200
0
00MHD2000200
0
DIODE 1SS176,MA165,1SS254 30V 0.1
A
P401 D407 00MHD2000200
0
00MHD2000200
0
DIODE 1SS176,MA165,1SS254 30V 0.1
A
P401 D408 00MHD2000200
0
00MHD2000200
0
DIODE 1SS176,MA165,1SS254 30V 0.1
A
P401 J191 00MYT02021390 00MYT02021390 TERMINAL 2P CINCH PIN JACK
(
T6743 BLK/BLK
)
P401 J401 00MYT02021390 00MYT02021390 TERMINAL 2P CINCH PIN JACK
(
T6743 BLK/BLK
)
P401 L401
/
K1G ns
p
00MLC1324001
0
CHOKE COI
L
320 MH CHOKE COIL
(
TOROIDAL
)
P401 L401
/
L1G ns
p
00MLC1324001
0
CHOKE COI
L
320 MH CHOKE COIL
(
TOROIDAL
)
P401 L401
/
N1G 00MLC1324001
0
00MLC1324001
0
CHOKE COI
L
320 MH CHOKE COIL
(
TOROIDAL
)
P401 L401
/
N1S 00MLC1324001
0
00MLC1324001
0
CHOKE COI
L
320 MH CHOKE COIL
(
TOROIDAL
)
P401 L401
/
S1G ns
p
00MLC1324001
0
CHOKE COI
L
320 MH CHOKE COIL
(
TOROIDAL
)
P401 L402
/
K1G ns
p
00MLC1324001
0
CHOKE COI
L
320 MH CHOKE COIL
(
TOROIDAL
)
P401 L402
/
L1G ns
p
00MLC1324001
0
CHOKE COI
L
320 MH CHOKE COIL
(
TOROIDAL
)
P401 L402
/
N1G 00MLC1324001
0
00MLC1324001
0
CHOKE COI
L
320 MH CHOKE COIL
(
TOROIDAL
)
P401 L402
/
N1S 00MLC1324001
0
00MLC1324001
0
CHOKE COI
L
320 MH CHOKE COIL
(
TOROIDAL
)
P401 L402
/
S1G ns
p
00MLC1324001
0
CHOKE COI
L
320 MH CHOKE COIL
(
TOROIDAL
)
P401 L403 00MLY2024048
0
00MLY2024048
0
RELAY MR82-24US
R
P401 L404 00MLY2024048
0
00MLY2024048
0
RELAY MR82-24US
R
P401 Q401 00MHF203691B0 00MHF203691B0 F.E.T. 2SK369 BL VGDS-40V PD0.4
W
P401 Q402 00MHF203691B0 00MHF203691B0 F.E.T. 2SK369 BL VGDS-40V PD0.4
W
P401 Q403 00MHF203691B0 00MHF203691B0 F.E.T. 2SK369 BL VGDS-40V PD0.4
W
P401 Q404 00MHF203691B0 00MHF203691B0 F.E.T. 2SK369 BL VGDS-40V PD0.4
W
P401 Q405 00MHT327052A0 00MHT327052A0 TRS. 2SC2705 O OR Y TAPING TOSHIB
A
P401 Q406 00MHT327052A0 00MHT327052A0 TRS. 2SC2705 O OR Y TAPING TOSHIB
A
P401 Q407 00MHC1002709
0
00MHC1002709
0
IC NJM5534D
P401 Q408 00MHC1002709
0
00MHC1002709
0
IC NJM5534D
53
