Marantz PM6006 - Part names and functions

Part names and functions
Front panel
.
uQ2 Q3oQ0 Q1iy
reqw t
A
Power operation button (X)
This turns the power on/off. (v p. 26)
B
Power indicator
This is lit as follows according to the power status:
0
Power on : Off
0
Standby : Red
0
Power off : Off
0
When the protection circuit is activated : Red (blinking)
